1PM120‐en‐US_V1.08/17

USERMANUAL



PM120–PowerMonitor



Introduction

ThankyouforselectingtheExtechPM120PowerMeter.ThePM120

monitorsandrecordspowerusageofhomeandworkappliancesfor

energyconservationandcostreductionanalysis.Thepowermeter

measuresthevoltage,current,power,andpowerfactoraswellastotal

time,cost,andenergy.ThePM120isequipped

withahigh‐precision

currentsensorgivingreal‐timemonitoringofACpowersupplyunits.It

featuresanalarmandpowercut‐offforsafety.

Thisdeviceisshippedfullytestedandcalibratedand,withproperuse,

willprovideyearsofreliableservice.Pleasevisitourwebsite

(www.extech.com)tocheck

forthelatestversionandtranslationsofthis

UserManual,ProductUpdates,ProductRegistration,andCustomer

Support.

Features



LargedualLCDmanuallydisplayselectrical,cost,andmetering

functionsinreal‐time.

Electricalsafetytransferfunctionwhenconnectingthisproductto

asocketandthenpluggingtheelectricalapplianceintothis

product.

Over‐currentwarningfunction.

PrimaryLCDshowsvoltage,current,power,powerfactor,or

frequency.

Secondarydisplayshowstotaltime,cost,set,orenergy.

Enterelectriccharge(costsetting)tocalculateanddisplaykWh.

Displaycostofoperationinminute,hour,day,andweek.

Batterybackupstoresdatawhenremovedfromoutlet.

ThreeprongstandardUSplugandfrontsocket

foreasyconnection.



SafetyInformation

Toensurethesafeoperationandserviceofthemeter,followthese

instructionsclosely.Failuretoobservewarningscanresultinsevere

injury.

WARNINGS

WARNINGSidentifyhazardousconditionsandactionsthatcould

causeBODILYHARMorDEATH.

Checkthehousingforcracksormissingplasticespecially

surroundingtheplug.Do

notuseifanypartofthemeteris

damaged.

Verifythemeter’soperation.Donotuseifthemeterresponds

abnormallyastheinternalstructuremaybedamaged.

UsethemeteronlyasspecifiedinthisUserGuideor

accompanyingQuickStarttoavoidcompromisingtheprotections

providedbythemeter.

Donotexceedtheratedpowerorcurrentofthismeter.

Donotexposethemetertoextremesintemperatureortohigh

humidity.

Keepthismeterawayfromchildren.

Donotusethemeterinthepresenceofexplosivegas,vaporor



dust.

Toreduceriskoffireorelectricshock,donotusethemeterifitis

wetanddonotexposethemetertomoisture.

MeterDescription

1.PrimaryDisplay:See↑M

forfunctions.

2.SecondaryDisplay:See↓M

forfunctions

3.↓M:Cyclesthrough

secondarydisplayfunctions:

TotalTime,Cost,Energyand

thecorrespondingvaluesof

eachselection.

4.↑M:Cyclesthrough

primarydisplayfunctions:

Voltage,Current,Power,

PowerFactor,Frequency

andthecorresponding

values

ofeachselection.

5.Applianceoutlet

6.SET:Longpresstosetthe

costin$/kWh

7.+/RESET:Shortpresstoincreasethedigits.Longpressto

resettheEnergyorCostfunctions.Shortpresstowakethe

powermonitorfromsleepmode.

Operation

Measurement

PlugthePM120intoahouseholdsockettobeingmeasuring.The

displaywillpoweronandenterdefaultmeasurementdisplay

(VoltageandTotalTime).



SelecttheMode

Shortpressthe↑Mbuttontoscrollthroughprimarydisplay

functions.ThemeterwillcyclethroughVoltage,Current,

Power,PowerFactorandFrequency.Longpress↑Mtoreturn

todefault‘Voltage’mode.

Shortpressthe↓Mbuttontoscrollthroughsecondary

displayfunctions.ThemeterwillcyclethroughTotalTime,

Cost,andEnergy.Longpress↓Mtoreturntodefault‘Total

Time’mode.

TotalTime

Checkthetimebypressingthe+/RESETbutton.Ifthe

accumulatedtimeislessthan1day,onlyHourandMinwill

display.Iftheaccumulatedtimeexceeds1day,theLCDwillonly

display‘Day’.Toviewthehourandminutedisplay,shortpress

the+/RESETbutton.



TotalTimeinDaysTotalTimeinHour:MinTotalTimesincepowerON



Note:Ifthemeterisabovetheratedcurrent,thedisplaywill

showawarningintheprimarydisplayandOLinthesecondary

display.Bothdisplaysandthepowerlightwillflash.



WarningIconandOverloadPowerOFF


