Pagina 1/12

7 Port USB 2.0 Metal HUB

for DIN Rail-

EX-1177HMV

7 Port USB 2.0 Metall HUB

für Trägerschiene

Manua

Anleitun

Vers. 1.2 / 08.02.24

Schweiz:

EXSYS Vertriebs GmbH

Dübendorfstrasse 17

8602 Wangen

www.exsys.ch

Deutschland:

EXSYS Vertriebs GmbH

Industriestraße 8

61449 Steinbach

www.exsys.de

- EX 1177HMV

1. Beschreibung···································································································· 3

2. Lieferumfang····································································································· 3

3. Aufbau, Anschlüsse & Jumper Einstellungen ························································· 4 5-

3.1 Aufbau························································································································ 4

3.2 Anschlüsse················································································································4 5-

3.3 Jumper Einstellungen ···································································································· 5

4. Hardware Installation ··························································································· 6

5. Treiber Installation ······························································································ 6

6. Reinigung ········································································································· 6

7. Technische Daten ······························································································· 7

8. Technische Zeichnung ························································································· 7

1. Description ······································································································· 8

2. Extent of Delivery ······························································································· 8

3. Layout, Connections & Jumper Settings ····························································· 9-10

3.1 Layout ························································································································ 9

3.2 Connections ············································································································ 9-10

3.3 Jumper Settings ·········································································································· 10

4. Hardware Installation ·························································································· 11

5. Driver Installation ······························································································· 11

6. Cleaning ········································································································· 11

7. Technical Information ························································································· 12

8. Technical Drawing ····························································································· 12

Inhaltsverzeichnis

Index

EX- 1177HMV Deutsch

Der EX-1177HMV ist ein USB 2.0 Metall HUB für bis zu 7 Endgeräte. Der Hub ist mit 7 Ports für

Endgeräte und 1 Port für den Anschluss an den PC ausgestattet. Er unterstützt alle USB Anschlüsse

von 1.1 bis 3.1. Jeder Anschluss an der EX-1177HMV ist zusätzlich verschraubbar. Durch die

Stromversorgung über den Terminal Block, werden an jedem Port die vollen 500mA zur Verfügung

gestellt. Der USB 2.0 Bus unterstützt optimal die Leistung des schnellen Terminus Chipsatz. Der EX-

1177HMV gewährleistet so eine sichere Datenübertragung und exzellente Performance von bis zu

480Mbit/s. Er unterstützt den Self Power und Bus Power Modus. Der EX-1177HMV unterstützt die

Norm IP30. Im Lieferumfang ist das DIN-Rail Kit für die Installation auf eine Trägerschiene enthalten.

Das DIN-Rail Kit wird mit vier Schrauben auf der Rückseite festgeschraubt.

Merkmale:

• Kompatibel zu USB 1.1, 2.0, 3.0 & 3.1

• Bis zu 480Mbit/s

• Es werden alle Betriebssysteme unterstützt

• Alle Anschlüsse sind verschraubbar

• Zertifiziert für

Bevor Sie den 1177HMV an Ihren PC anschließen, überprüfen Sie bitte zuerst den Inhalt der EX-

Lieferung:

• EX-1177HMV

• USB 2.0 Kabel (verschraubbar)

• DIN Rail Kit-

• Anleitung

1. Beschreibung

2. Lieferumfang

Product specificaties

Merk:	EXSYS
Categorie:	Niet gecategoriseerd
Model:	EX-1177HMV
Kleur van het product:	Zwart
Gewicht:	250 g
Materiaal behuizing:	Metaal
Interface:	USB 2.0
Compatibele besturingssystemen:	98SE/ME/2000/XP(32&64)/Vista(32&64)/Win7(32&64)\nWIN CE/Server(2000, 2003 & 2008), Linux, MAC
Mac-compatibiliteit:	Ja
Afmetingen (B x D x H):	114.5 x 73 x 26.3 mm
Chipset:	NEC uPD720113
Overdrachtssnelheid:	480 Mbit/s
Aantal poorten:	7
