As its name suggests, the Erica Synths DJ VCF STEREO module

provides sound treatment functionality typically found on DJ

decks – it is fully open when the cutoff knob is at 12:00. When

turned counter-clockwise, lowpass filtering is applied and when

turned clockwise, highpass filtering is initiated. Additionally, there

is an nice-sounding, adjustable resonance parameter. This

provides hands-on control over the sound during performances

as well as unconventional timbre modulations that are hard to

achieve with conventional state variable filters. The DJ VCF

STEREO features a fully-analogue design and consists of two

pairs of VCFs – highpass and lowpass in series and the filter

management is done via complex CV routing.

SPECS

Audio level 10Vptp

CV level -10V - +10V

Filter slope 24dB/oct

Power consumption +109mA, -101mA

Module width 8HP

Module depth 35mm

SAFETY INSTRUCTIONS

Please follow the instructions for use of the Erica Synths

module below, ‘cause only this will guarantee proper operation

of the module and ensure warranty from Erica Synths.

Water is lethal for most of the electric devices, unless they are made waterproof.

This Erica Synths module is NOT intended for use in a humid or wet environment.

No liquids or other conducting substances must get into the module. Should this

happen, the module should be disconnected from mains power immediately, dried,

examined and cleaned by a qualified technician.

Transport the instrument carefully, never let it drop or fall over.

Warranty does not apply to modules with visual damages.

Do not expose the module to temperatures above +50° C or below -20° C.

If you have transported module in extreme low temperatures, leave it in

room temperature for an hour before plugging it in.

The module has to be shipped in the original packaging only. Any module

shipped to us for return, exchange and/or warranty repair has to be in its

original packaging. All other deliveries will be rejected and returned to you.

Make sure you keep the original packaging and technical documentation.

This device complies to the EU guidelines and is manufactured RoHS conforming

without use of lead, mercury, cadmium and chrome. Nevertheless, this device is

special waste and disposal in household waste is not recommended.

You will find Erica Synths terms of warranty at

www.ericasynths.lv

Items for return, exchange and/or warranty repair have to be

registered at SUPPORT on www.ericasynths.lv and send back

to us according to instructions in the support page.

User manual by Girts Ozolins@Erica Synths.

Design by Ineta Briede@Black8.

Copying, distribution or any commercial use in any way is prohibited

and needs the written permission by Erica Synths. Specifications are

subject to change without notice.In case of any questions, feel free

to contact us through www.ericasynths.lv.

THANK YOU FOR PURCHASING

THE ERICA SYNTHS

DJ VCF STEREO MODULE!

The Erica Drum Series includes high-end, unique

functionality and superior quality modules which allow

for designing an extensive, feature rich modular system

for sound design and live performances in genres such

as techno, industrial and DnB. Enjoy!

FEATURES

Fully analogue stereo DJ style VCF

Manual cutoff and resonance control

Two cutoff CV inputs, one with an attenuverter
