Featuring the new
MSD PlatinuM 5r
PLATINUM BEAM
5R PRO
Wide Frost
(
Hybrid
)
and eWdMX
Sku# EPB832
Specications are preliminary & are subject to change without notice ©Elation Professional • Los Angeles, Ca USA • Kerkade, Netherlands
www.elationlighting.com
Toll Free
(
866
)
245-6726
The Platinum Beam 5R Pro is a compact, light weight, high power
ACL beam aerial effect moving head xture. Featuring a Wide Frost
(
Hybrid
)
and EWDMX, the new MSD Platinum 5R lamp from Philips a
189W lamp offering output comparable to 575W xtures and with
the specialized optical design in the Platinum Beam 5R creating
a concentrated beam of light “ACL / Searchlight” type effect, it
competes even with the most powerful units on the market. Featuring
12 dichroic colors, 8 Rotating indexing gobos, Rotating 8 facet prism,
Frost Filter for “wash” effect and lighting fast 3-phase motors for pan/tilt.
Product Features
• Wide Frost
(
Hybrid
)
• EWDMX
• Extreme ACL / beam effect
• 2.5° Beam angle
• Rotating gobos and 8 facet prism
• Frost effect for wash
• Featuring new Philips MSD Platinum 5R lamp
• 12 dichroic colors
• 8 rotating replaceable rotating / indexing gobos
• Gobo Size 14mm OD / 8mm ID
• 3 Facet rotating prism
• Frost lter (hybrid effect for wash)
• ETL listed
Technical Specifications
• DMX Channels: 11/13/16
- 3 x DMX channel modes
• Control: 3-pin & 5-pin DMX
• Dimmer: Mechanical Dimmer 0-100%
• Strobe: Variable speed Shutter / Strobe
• Pan/Tilt: 540/630 x 265
• Power Supply: 120v-240V 50/60hz
• Power Consumption: 350W MAX
• Lamp: MSD Platinum 5R Philips
• Lamp life: 2,000hr
• Lux: 28,360 Lux / 2,634 fc @ 75’
• Dimensions: ( L x W x H ) 14.1” x 13.2” x 18.5 /
358 x 335 x 470 mm
• Weight: 34.2 lbs / 15.5 kg
PLATINUM BEAM
5R PRO
Wide Frost
(
Hybrid
)
and eWdMX
Sku# EPB832
Specications are preliminary & are subject to change without notice ©Elation Professional • Los Angeles, Ca USA • Kerkade, Netherlands
www.elationlighting.com
Toll Free
(
866
)
245-6726
Colors and Gobos
Photometric Data
1-4>
5-8>
Color
PLATINUM BEAM 5R EXTREME(V160B PRO)
Rotating gobos
1
>
8
>
Platinum Beam 5R
Photometric Beam Angle Data
Standard 2.5° Beam Angle
LUX
x
0.0929
= FC
5207 FC / 56230 LUX 2635 FC / 28360 LUX 1680 FC / 18080 LUX
2.5° Beam Angle
0 m
0 ft
2.5 m
8.20 ft
7.5 m
24.60 ft
5.0 m
16.40 ft
Ø 0.65 m / Ø 2.13 ft
Ø 0.86 m / Ø 2.82 ft Ø 1.06 m / Ø 3.50 ft
Beam Diameter
2.5° Beam Angle
