User

Instruction

MIDIPAK

Technical Specifications:

Model - MidiPak

Voltage: AC 120v - 60Hz

Channel Output:

5A/CH, 15A MAX

(600W per ch.)

Channel Fuse:

6.3AAGC

Dimentions: 7.75 x 6.5 x 2.75

Weight:

7lbs.

Thank you for purchasing the MidiPak byElation Professional®. The MidiPak can be used as a stand

alone chaser, or can be controlled by a DMX controller or through MIDI. This unit is designed to be hung

on to trussing or a light stand. The MidiPak can be remotely controlled with the optional MidiPak Remote.

This model is a 4 channel DMX & MIDI power pack, it has

RECEIVING & CHASING operating modes, built-in

EPROM is incorporated with this unit to store operating mode and programming options.

Elation Professional. www.elationlighting.com Los Angeles, CA. 90058 Page1

CAUTION: Read all instructions before plugging the unit in !

MidiPak Introduction

M

idi

P

ak Controls & Functions

1. CHANNEL OUTPUT: 5A per channel, 15A MAX

2. CHANNEL LEDs: They are lit when the corresponding channel is ON.

3. LCD DISPLAY: Shows the operating mode and function parameter specified as follows:

On:01 - On:16 MIDI-IN CHANNEL

N:001 - N:128 NOTE NUMBER

D:001 - D:512 DMX CHANNEL

P:01 - P:16 CHASE CHANNEL

SP:01 - SP:99 CHASE SPEED

d:000 - d: 100 CHASE DIMMER

4. MODE BUTTON: Press to select operating mode from RECEIVE and CHASE modes.

5. MENU BUTTON: Press to select display item in LCD.

Press MODE + MENU BUTTONS to select RECEIVE mode between

Seperate and Parallel modes.
