Powered Bookshelf Speaker

R2750DB MKII

Quick Sta Guide

Model: EDF100102

EN

1. EDIFIER ConneX app

2. What’s in the box?

3. Cable connection

EDIFIER ConneX app

With this app, you can

•control play from the Bluetooth

source device,

•control the master volume,

•upgrade the rmware, and

•more functions.

Download EDIFIER ConneX app

1. With your sma device, scan the QR code on the quick sta guide or the packaging.

•You can also search for "EDIFIER ConneX" in Apple App Store (iOS devices) or Google Play

(Android devices).

2. Download and install the app.

How to use this app

1. Connect your sma device with the speaker via Bluetooth.

2. In Bluetooth mode, open EDIFIER ConneX App on your sma device.

3. Tap the menu for settings and playback control.

A A A

A A A

Note:

•Images are for illustrative purpose only and may dier from the actual product.

•For the need of technical improvement and system upgrade, information and specications contained

herein may be slightly dierent from actual product. If any dierence is found, the actual product prevails.

4. Power on/o

5. Power saving function

10. Batte replacement

11. Specications

VOLUME

SOURCE

BASSTREBLE

*

ON

Note:

•Power input: 100-240 V~ 50/60 Hz 600 mA

•HDMI eARC Connection: Use an Ultra High Speed HDMI™ cable (not included) to connect the speaker’s

HDMI eARC po to the HDMI eARC or ARC po on your TV or source device.

•Refer to the user manual of your TV or source device for HDMI settings: (1) Enable the HDMI eARC or ARC

function. (2) Set the digital audio output format to PCM. (3) Enable the HDMI CEC function to control the

speaker with your TV or source device remote (e.g., standby/wake-up, mute, volume).

* This plug type is meant for illustrative purpose only.

** The subwoofer is not bundled. To connect it with a subwoofer, another suitable audio cable may be required.

•Power on: Switch the main power button on the rear panel of the active speaker to "ON".

•Power o: Switch the main power button to "OFF".

1. In Bluetooth (or HDMI) input mode, the speaker will enter power saving mode after 15 minutes of inactivity

(no audio playback and operation) if any Bluetooth device (or HDMI source device) is connected. When

playback resumes, it will return to working mode in about 1 second.

2. In Bluetooth (or HDMI) input mode, the speaker will automatically power o after 15 minutes of inactivity

(no operation) if no Bluetooth device (or HDMI source device) is connected.

3. In Line In, Optical, or Coaxial input mode, the speaker will automatically power o after 15 minutes of

inactivity (no audio playback and operation).

Note: This function is enabled by default. To disable or re-enable this function, lower the volume to 0, and

then press and hold the " " button on the remote control for 2 seconds. "ECO OFF" will be displayed on the

screen to conrm the function has been disabled. Otherwise, "ECO ON" will be displayed. You can disable this

feature in the menu of "My Device" > "Power Saving Mode" on EDIFIER ConneX App.

Total output power (RMS): 12 W+12 W (Treble), 20 W+20 W (Mid), 40 W+40 W (Bass)

Frequency response: 45 Hz ~ 40 kHz

Declaration for EU

Frequency Band: 2.402 GHz ~ 2.480 GHz

RF Power Output: ≤13 dBm (EIRP)

There is no restriction of use.

12. Troubleshooting

VOLUME

SOURCE

BASSTREBLE

9. Play control

Note: Volume sync is not suppoed. To adjust the volume, adjust on the speaker and your device separately.

OPTHDMICOAX

x1

x1

x1

x1

VOLUME

SOURCE

6. Standby & wake-up

VOLUME

SOURCE

BASSTREBLE

VOLUME

SOURCE

1.5s

1.5s

OPTHDMICOAX

x1

7. Source selection

LINE IN

HDMI

OPTICAL

COAXIAL

VOLUME

SOURCE

x1

OPTHDMICOAX

x1

AAA

AAA

Cannot connect to your Bluetooth device

•

Make sure that the distance between this product and your Bluetooth device

is less than 10 meters and there are no obstacles between them.

•

Make sure that no device is connected to this product via Bluetooth.

•

Make sure that this product is in Bluetooth pairing mode. If not, manually

switch it to this mode.

•

Resta this product, enable Bluetooth function on your Bluetooth device,

and then t again.

No sound

•

Make sure that this product is powered on.

•

Make sure that this product and your device is properly connected.

•

Make sure that the playback is not paused.

•

Make sure that this product and your device are not muted.

•

Increase the volume of this product and your device.

Noise coming from speakers

•

EDIFIER speakers generate little noise, while the background noise of some

audio devices is too high. Please unplug audio cables and turn the volume

up. If no sound can be heard at 1 meter away from the speaker, there is no

problem with this product.

To learn more about EDIFIER, please visit www.edier.com

For EDIFIER warranty queries, please visit the relevant count page on

www.edier.com and review the section titled Warranty Terms.

USA and Canada: seice@edier.ca

South America: Please visit www.edier.com (English) or

www.edierla.com (Spanish/Pouguese) for local contact information.

8. Bluetooth connection

This speaker suppos the simultaneous connection of two Bluetooth devices.

Connect to a device

1. Press the "VOLUME/SOURCE" knob on the active speaker or the " " button on the remote control to

switch to Bluetooth input mode. If no device is connected, the speaker will auto-enter Bluetooth pairing

mode (" " blinking on the screen). If not, double-press the "VOLUME/SOURCE" knob on the active

speaker or press and hold the " " button on the remote control for 1.5 seconds.

2. On your device, select "EDIFIER R2750DB MKII" in its Bluetooth device list to connect, and " " will be

steady displayed on the screen when the connection is established.

•To disconnect from the current Bluetooth device, double-press the "VOLUME/SOURCE" knob on the active

speaker or press and hold the " " button on the remote control for 1.5 seconds.

Connect to two devices

1. Connect to a device, and then double-press the "VOLUME/SOURCE" knob on the active speaker or press

and hold the " " button on the remote control for 1.5 seconds (" " blinking on the screen).

2. On the second device, select "EDIFIER R2750DB MKII" in its Bluetooth device list to connect, and " " will

be steady displayed on the screen when the connection is established.

3. On the rst device, select "EDIFIER R2750DB MKII" in its Bluetooth device list to reconnect.

•Pause or stop playback on the current Bluetooth device before streaming audio from the second one.

Note:

•If no device is connected in 10 minutes, the speaker will switch to Bluetooth hidden mode (" " displayed in

breathing pattern on the screen). In this mode, (1) new devices cannot nd the speaker, but (2) for a device

that exists in the pairing record of this speaker, you can select "EDIFIER R2750DB MKII" from its Bluetooth

device list to reconnect. To exit from Bluetooth hidden mode, press the "VOLUME/SOURCE" knob on the

active speaker or the " " button on the remote control.

•After switched to Bluetooth input, the speaker will reconnect to the last connected devices automatically.

Bluetooth

Settings

EDIFIER R2750DB MKII

DEVICES

Bluetooth

2:12

VOLUME

SOURCE

BASSTREBLE

TV

TV

**

*
