Pagina 1/4
OWNER'S MANUAL
ZXI-574
5X7
"
2-WAY COAXIAL SPEAKER
PAIR
Grills Included
ZXI-574
3.70" / 94mm
4.92X7.07" / 125X179.5mm
2.84" / 72mm
2.22" / 56.5mm
8.07" / 205mm
4.19" / 106.5mm
4.91" / 124.7mm
7.60" / 193mm
5.55" / 141mm
ZXI-574
5X7
"
2-WAY COAXIAL SPEAKER
5x7”
4 ohm
70 Watts
210 Watts
91dB
40Hz-20KHz
60Hz
2-Way
1” / 25.5mm
KSV
EISV
Glass fiber
Rubber
Steel
Barium Ferrite
14.46 oz / 410g
1" (25.4mm)
0.8"(ø20.4mm)
KSV
EISVM
PEI
Neodymium
0.3 oz / 8.5g
8.66L
2.7mm
68Hz
7.04
1.28
1.08
16.1g
258.7mm/N
4.66
228mH
153.5cm2
3.5 ohm
14g
5.55x7.60” / 141x193mm
2.84” / 72mm
4.92x7.07”/ 125x179.5mm
2.22” / 56.5mm
3.70” / 94mm
Specifications
Nominal Diameter..................................................
Nominal Impedance..............................................
RMS Power Handling.............................................
MAX Power Handling............................................
Sensitivity (1w/1m)................................................
Frequency Response.............................................
Recommended HI Pass Crossover.......................
Speaker Type.........................................................
Midrange:
Voice Coil Diameter ..............................................
Voice Coil Former Material ...................................
Winding Material ..................................................
Cone Material .......................................................
Surround Material ................................................
Basket Material .....................................................
Magnet Material....................................................
Magnet Weight......................................................
Tweeter:
Nominal Diameter..................................................
Voice Coil Diameter...............................................
Voice Coil Former Material ..................................
Winding Material ..................................................
Diaphragm Material...............................................
Magnet Material....................................................
Magnet Weight......................................................
Thiele & Small Parameters
Equivalent Volume
Excursion (one way)
Free Air Resonance
Mechanical Factor
Electrical Factor
Total Factor
Mechanical Mass
Mechanical Compliance
BL Factor
Voice Coil Inductance
Cone Area
DC Resistance
Mechanical Mass w/o air
Measurements
Overall Diameter ...................................................
Overall Depth ........................................................
Front Mount Baffle Cutout ....................................
Mouting Depth ......................................................
Motor Diameter ....................................................
Vas.................
Xmax.............
Fs ..................
Qms ...............
Qes................
Qts.................
Mms...............
Cms...............
BL...................
Le...................
Sd..................
Re...................
Mmd...............
