1,2,3,4 Attenuinverters INPUTS
Sets the Amount of 1,2,3,4 Attenuinverters
1,2,3,4 Attenuinverters OUTPUTS
Mixer INPUTS
nomalised to the above patch
Mixer OUTPUTS
3 identical
Pulserizer INPUT
normalised to the mixer out
Sets the of the PulserizerOFFSET
Sets the LFO Rate
LFO CV Input
Accepts +/-5V
USER’S MANUAL
Useful Notes
- Utopia is a very handy and useful tool for your modular system. Many hidden functions (such as , compressed , SplitterVCASquare
Wave LFO and more) are there to be discovered.
- In order to use the or the without sending these to the mixer below, just patch a dummy cable to IN C or IN D.LFO OFFSET
Pulserizer OUTPUT
Sends +/-5V
LFO Triangle Output (sends +/-5V)
unless something is patched to the LFO (4)
OFFSET Output (sends +/-10V)
unless something is patched to OFFSET (3)
