USER’S MANUAL
Useful Notes
-The Low Pass Filter is a 24dB/ocv (4-pole) resonant one, while the High Pass Filter is an 18dB/ocv non-resonant.
-The VCA LED, will go from Orange to Red when the Output Level exceeds +/-5V.
-When sending a 10Vpp Input to the Mixer, the Mixer Level should be at about 50% so as to get a nice clean output.
Over that, a Filter overload may occur.
Low Pass Filter’s Cut Off CV Input
Accepts +/-5V
Sets the Low Pass Filter’s Cut Off
Sets the High Pass Filter’s Cut Off
1V/ocv Low Pass Filter Cut Off CV Input
Accepts +/- 12V
High Pass Filter CV Input
Accepts +/-5V
VCA CV Input
Accepts +/-5V
Main Output
Sets the Initial VCA Level
Sets the Resonance for the Low Pass Filter
Audio MIXER INPUTS corresponding to
the control knobs below them
