The Model IL64Ais a single-channel instrument which is an easily configured,rugged, analog based signal
conditioner made to operate with traditional DC sensor sources,such as string potentiometers,DC LVDTs
and other sensors to measure force, pressure, torque,displacement and related measurements. The
Model IL64A has an extremely wideDC signal input range with user selectable gain, zero and anaolg
output making it adaptable to any sensor application that requires stable, repeatableand noise free
analog signals for control or data acquisition requirements.
1GENERALDESCRIPTIONANDSPECIFICATIONS
IN-LINE DC Voltage & mA Conditioner
MODELIL64A
DC Voltage & mA
C
ONDITIONERModule
IL64A
GENERAL DESCRIPTION ANDSPECIFICATIONSIL64.1
Top view of the Model IL64A DC Voltage Module (cover removed))
4-20 mA Input Operation
The Model IL64Acontains a precision input shunt resistor for mA signal input on pin 7 of
the transducer input connector.Referto
Fig.1 forwiring information.
92373.00 rev. B
