Pagina 1/136

Web UI Reference Guide

Ver. 2.10

DGS-1100 Series Switch Web UI Reference Guide

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of D-Link Corporation is strictly

forbidden.

Trademarks used in this text: D-Link and the D-Link logo are trademarks of D-Link Corporation; Microsoft and

Windows are registered trademarks of Microsoft Corporation.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the

marks and names or their products. D-Link Corporation disclaims any proprietary interest in trademarks and

trade names other than its own.

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in accordance with this user’s guide, may

cause harmful interference to radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference in which case the user will be required to correct the interference at his own

expense.

Innovation, Science and Economic Development Canada (ISED) Statement

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

VCCI-A Warning

この装置は、クラス A 情報技術装置です。この装置を家庭環境で使用すると電波妨害を引き起こ

すことがあります。この場合には使用者が適切な対策を講ずるよう要求されることがあります。

Japan Voluntary Control Council for Interference Statement

This is a Class A product based on the standard of the Voluntary Control Council for Interference (VCCI). If this

equipment is used in a domestic environment, radio interference may occur, in which case the user may be

required to take corrective actions.

警告使用者:

此為甲類的資訊技術設備，在居住環境中使用時，可能會造成射頻擾動，在這種情況下，使用者會被要

求採取某些適當的對策。

Warning:

This is a class A product. In a domestic environment this product may cause radio interference in which case

the user may be required to take adequate measures.

Product specificaties

Merk:	D-Link
Categorie:	Schakelaar
Model:	DGS-1100-24PV2
Kleur van het product:	Zwart
Gewicht:	2200 g
Breedte:	280 mm
Diepte:	230 mm
Hoogte:	44 mm
Geluidsniveau:	0 dB
LED-indicatoren:	Ja
Frequentie van processor:	125 MHz
Vermogensverbruik (max):	19.5 W
Certificering:	EMI FCC A, CE A, VCCI A, C-Tick, BSMI, CCC\ncUL, CE LVD, CB, BSMI, CCC
Type processor:	Ja
Netwerkstandaard:	IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ondersteunde beveiligingsalgoritmen:	SNMP, SSL/TLS
Temperatuur bij opslag:	-40 - 70 °C
Web-gebaseerd management:	Ja
Luchtvochtigheid bij opslag:	0 - 95 procent
Rack-montage:	Ja
Flash memory:	16 MB
Mean time between failures (MTBF):	255003 uur
Hoogte, in bedrijf:	0 - 2000 m
Quality of Service (QoS):	Ja
VLAN=ondersteuning:	Ja
Auto MDI/MDI-X:	Ja
Virtuele LAN-functies:	Port-based VLAN, Voice VLAN
Power over Ethernet (PoE):	Ja
Type geheugen:	DRAM
Switchingcapaciteit:	48 Gbit/s
MAC-adrestabel:	8000 entries
10G support:	Nee
Datastroombeheer:	Ja
Rate limiting:	Ja
Aantal VLANs:	128
IGMP snooping:	Ja
Switch type:	Managed
Multicast-ondersteuning:	Ja
Aantal basis-switching RJ-45 Ethernet-poorten:	24
Switch-laag:	L2
Type basis-switching RJ-45 Ethernet-poorten:	Gigabit Ethernet (10/100/1000)
Packet buffergeheugen:	4.1 MB
Jumbo Frames ondersteuning:	Ja
Port mirroring:	Ja
Spanning tree protocol:	Ja
Verbindingsaggregatie:	Ja
Full duplex:	Ja
Koperen ethernetbekabelingstechnologie:	10BASE-T, 10BASE-TX, 1000BASE-T
DHCP-functies:	DHCP client
Warmtedissipatie:	107.5 BTU/h
Auto-negotiation:	Ja
AC-ingangsspanning:	100 - 240 V
Bedrijfstemperatuur (T-T):	-5 - 50 °C
Relatieve vochtigheid in bedrijf (V-V):	0 - 95 procent
Code geharmoniseerd systeem (HS):	85176990
Totaal Power over Ethernet (PoE)-budget:	100 W
Aantal Power over Ethernet plus (PoE +)-poorten:	12
Verzending snelheid:	35.71 Mpps
Jumbo frames:	9216
Broadcast stormbeheer:	Ja
Fanloos:	Ja
Store-and-forward:	Ja
System event log:	Ja
Vermogen per poort Power over Ethernet (PoE):	30 W
Head-of-line (HOL) blocking:	Ja
Aantal wachtrijen:	4
Algoritmen wachtrijplanning:	SPQ, Weighted Round Robin (WRR)
