WILBURCURTIS.COM

1

Find out more

ontheweb.

WILBURCURTIS.COM

WILBUR CURTIS COMPANY

Montebello, CA 90640

Models Included

ILGD

TL-ILGD

CAUTION: Please use

this setup procedure

before attempting to use

this grinder. Failure to follow the

instructions can result in injury or the

voiding of the warranty.

WARNING TO AVOID

SCALDING, Do not

remove brewcone whil

brew light is ashing.

ISO 9001 REGISTERED

C

Service Manual – Digital InterLock Coffee Grinders

For the Latest speciFications and inFormation go to www.wiLburcurtis.com

This appliance is designed for commercial use. Any servicing other than cleaning and maintenance should be performed by an autho-

rized Wilbur Curtis service center.

•DoNOTimmersetheunitinwateroranyotherliquid

•Toreducetheriskofreorelectricshock,doNOTopentoppanel.Nouserserviceablepartsinside.Repairshouldbedone

only by authorized service personnel.

•Keephandsandotheritemsawayfromhotpartsofunitduringoperation.

•Nevercleanwithscouringpowdersorharshimplements.

Important Safeguards/Conventions

Conventions

WARNINGS–TohelpavoidpersonalinjuryImportantNotes/Cautions–fromthefactory

QUICKSTART&SETUP

SETUP

1.Installthegrinderonarm,levelbaseinalocationwhereitcanbeconnectedtoagroundedelectricaloutletof120VAC,ratedat15

amps.

2.Testtheunitbyrunningsomewholebeancoffeethroughthegrinder.Ifanyproblemsareencountered,refertothetroubleshooting

sectioncompleteatwww.wilburcurtis.comorcallTechnicalSupportat800-995-0417.

CONNECTINGTHEINTERLOCKGRINDER

1.TurnbothunitsOFF.

2.PlacethegrindercloseenoughtothebrewersoittheInterLockcablewillreachthebrewer.

3.Locatethejack,labeledCLASS2WIRINGONLY,onthebackofthebrewer.PlugintheInterLockcabelfromthegrinder.

4.TurnbothunitsON.Interlockingiscomplete.

INTERLOCKOPERATINGINSTRUCTIONS

1.Openthedoorontopofthegrinderandllwithfreshwholebeancoffee.Closethetopdoor.

2.PlaceanemptySatelliteonthewarmerdeckofthebrewerandpreheatitbyswitchingonwarmer.

3.Placeanewpaperlterintothebrewcone.

4.Insertthebrewconeintothebasketholderarmsonthegrinder.

5.Presstheappropriategrindswitch(SMALL,MEDIUMorLARGE).

6.Allowthegrindmotortocompletelystopbeforeremovingthebrewcone.Thebrew

selectionisnow“Locked”inatthebrewerandisindicatedbytheashinglightonthe

InterLockbrewer.

7.Transferthelledbrewconetothebrewerandpresstheashingbrewbutton.

Brewcycleiscompletewhenthebrewlightstopsashing.

ADJUSTINGTHEGRINDS

1.Emptyhopperofcoffeebeans.Rungrindertocleargrindingburrsofcoffee.

2.Openhousingcovertolocateadjustmentscrew(8)andlocknut(7).Loosenlocknut.

3.Runmotorduringadjustment.Turningadjustmentscrewclockwisewillresultinaner

grind(if,whileturning,youhearthegrindingburrsstartingtotouch,immediately,back

off1/8thturn).Turningcounterclockwisewillproduceacoarsergrind.

4.Withascrewdriverholdingtheadjustmentscrewinplace,tightenthelocknut.

5.Runsomecoffeebeansthroughthemachinetocheckthegrindadjustment.

6.Replacefrontcoveronmachine.

*Thisadjustmentmaychangetheamountofgroundcoffeedispensed.

CHANGINGABROKENSHEARDISK

1.Unplugthepowercord.

2.Emptythehopperofbeans.

3.Takeoutthethumbscrews(10)toremovethegrindcap(6).

4.Pulloutthegrindingburr/feedwormassembly(2).Theinnerhalfofthegrindingburrset

willremaininthehousing.

5.Separatetheshearcap(5)andsheardrive(3).Thesnappedsheardisk(4)shouldfall

out of it’s slot on the shear drive.

6.Inspectandcleanhousing(1)ofanycoffeeordebris.Especiallylookforanythingthatmayhavebrokenthesheardisk.

7.Re-insertthefeedwormandgrindingburrontothemotorshaft.

8.Pushsheardrivethroughburr/feedwormassemblyandalignlargeslotwithtongueonthemotorshaft.

9.Rotateburr/feedwormassemblytoalignslotwithnarrowslotonsheardrive.

10.Insertanewsheardiskintoslot.Coverwiththeshearcap.

11.Replacegrindcapandthumbscrews.

Wilbur Curtis Company, inC.
