ASSEMBLY INSTRUCTION MODEL #DEL90808AG

LIGHTING THE WAY FOR SIXTY YEARS

WARNING:

Electrical Danger

Turn Power Off

You will need 8- Candelabra Base Bulb

40 Watts recommended 60 Watts Max.

USE LED BULBS FOR EXTENDED USE

All electrical components must be

installed by a licensed electrician

in accordance with the National

Electric Code and the appropriate

local electrical codes

The fixture is Dry rated

WARNING:This product can expose you to Lead,

which is known to the State of California to cause cancer

and/or birth defects or reproductive harm.For more

information go to www.p65warnings.ca.gov

HOW TO INSTALL:

Place the fixture parts on a soft

cloth-covered platform before

installation of fixture.

1. Install the mounting bar onto the

outlet box.

2. Decide the desired hanging height and

adjust the chain to the correct length.

5. Raise the fixture up and do the wire

connection. Attach the canopy over the

mounting bar and secure with collar ring.

6. Dress the crystals as illustrated.

Crystal Sets

3. Spread the arms out equally.

Place the metal ring inside the arms and

align the holes on it with the holes in the

arms.

Secure the metal ring with ball nuts.

(please do not bend the arms out too hard

when place the ring inside.)

Spread the folded arms.

E

C

B

D

A

4. Place the check ring on the top of fixture

body and secure the fixture loop.

31 1/2"

37"

111"

From one arm

to next arm

From one arm to

every other arm

A. 8 Sets. (2)14mm

B. 8 Sets. 370mm long bead string--(10mm bead*24pcs)

C. 8 Sets. 910mm long bead string--(10mm bead*59pcs)

D. 1 Piece. (1)AS8-50mm Ball

E. 1 Piece. 750mm long bead string--(10mm bead*58pcs)

Crystorama.com

D is hung on E

B

C

1

2

3

4

5

6

7

8

1

4

3

6

2

5

47

5

8

6

1

7

2

8

3

Dress Crystal Strands C in the

following sequence:
