CSV-2540 QUICK INSTALLATION GUIDE

Thank you for purchasing our CSV-2540.

After unpacking the product, please make sure you have all the items provided and checked

for any damages. In case of any missing damaged parts please inform your s

You should have:



1x CSV-2540 Docking Station



1x USB-C® 1m/3.28 ft cable for host connection



1x Power Supply 150Watt

How does it work?

1Please connect one end of the black USB-C® cable to the Dock and connect the

other side of that cable to the USB-C® port of your Notebook/Host system.

2Connect your preferred Display(s) to the designated connector(s) and power on

your Display unit(s) , peripherals, ethernet and/or sound devices.

3Connect the Power Supply connector to the dock.

4Now plug the Power Supply in a wall socket and switch the Dock ON, the BLUE

indicator should be lit!

Note

The DOCK will work only when it is

connected to DC power supply.

If it is not connected to the DC power

supply, the DOCK will NOT function.

Please make sure that

Your Host System has the latest drivers updates installed

Your HostSystem supports DisplayPort Alt Mode

Follow the QIG installation steps

You’re ready to start working and enjoy the full benefi ts of your CSV-2540Dock.

Warning Safe Usage: Only to be used at altitude 2000 meters/6562 feet and below.

For any Questions, please check our forum section on our website www.club-3d.com

How does it work?

Point 1

USB-C®

PD thos

DC

Power Jac

k

2x HDMI™

2x DisplayP ort™

Ethernet

2.bps5G

USB-A

5Gbps

USB-C®

5Gbps

Audio/Mi

c

MicroSD/SD

4.0

USB-A

10Gbps

2x USB-C®

10Gbps

Power

Switch

Kensington

Security Slot™

Kensington

Nano Security Slot™

CSV-2540 QIG May 2025

14-1 USB-C® Quad Display Docking Station

Please use one of our Extension/Adapter cables to connect to your devices: In case you

need assistance to choose the correct cable, please visit our website www.club-3d.com

or feel free to mail us at support@club-3d.com and it will be our pleasure to assist you.

Club 3D uses Bio-Degradable bags

according to the EN/DIN 13432.

COMPOSTABLE

BIODEGRADABLE BAG

Club 3D uses environmentally friendly packaging

and is printed on recycled paper.
