1 947602

CAUTION: To reduce the risk of electric shock,

Do not remove cover.

No user serviceable parts inside.

Refer servicing to qualified service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.

I6 ssue

SM120

RACK MOUNT 120 WATT AMPLIFIER

INTRODUCTION

These instructions contain the specifications and

information necessary to install, operate and

maintain the SM120, 120 Watt Mixer-Amplifier.

The SM120 provides up to 120 Watts of audio

power for voice paging or background music

systems.

SPECIFICATIONS

Access Methods

• Paging and Sound Reinforcement Systems

• Stand Alone Background Music Systems

Features

•Active mix or Priority override on inputs

(override is voice operated)

•RM ack ount

•Mic 1/Tel on Input 1, 3 standard plus

MIC/AUX inputs

• Volume control for each input

•V Master olume, Bass and Treble Controls

• Overload limiting circuit protection

• Screw terminals for all connections

• Power "ON" indicator

•s Clipping indicatorand Fault

•8 - - Ohm, 25and 70Voltselectable output

•a Tone generator (Wrble or Continuous)

• Optional external volume control

Dimensions and Weight

•1. 17.0" W x 12.0" D x 75" H

(43.204.4 3cm W x 3.5cm D x cm H)

• .3 Weight: 5.1 lbs. (2kg)

Nominal Specifications

Wattage Output 120 Watts Peak

Type Outputs 8 Ohm or 25V or 70V

Frequency Response 20 to 20kHz +/ -

2dBm

Distortion < 2% @ 1kHz Rated Output

Number of Inputs4 (1 Mic/Tel Line,

3

Mic/Aux)

Voice Switch Sensitivity 31dBm

Mic Input Impedance600 Ohms Balanced

Mic Input Sensitivity 1.0mVRMS

Tel Line Input Impedance600 Ohms

Tel Line Sensitivity 7 0mVRMS

Aux Input Impedance 10K Ohms

Aux Input 200mVRMSSensitivity

Line Out Impedance 10K Ohms

Line 1VRMSOut Level

Nominal Power Requirements

115 or 230 VAC @ 75W

Environment

Temperature 04 0 to +40° C +32° to +1° F

Humidity 0 to 85% non- precipitating

Precautionary Designations

•WARNING-To Reduce The Risk Of Fire Or

Electric Shock. Do Not Expose This

Apparatus To Rain Or Moisture.

•AVERTISSEMENT - Afin de réduire les

risques d'incendie ou de décharge

électrique, évitez d'exposer le système à

la pluie ou à l'humidité.

•Apparatus shall not be exposed to

dripping or splashing and no objects

filled with liquids, such as vases, shall be

placed on the apparatus.

•L’appareil ne doit pas être exposé à des

égouttements et éclaboussures et aucun

Objet Rempli de liquide, comme vase, ne

doit être place sur l’appareil.
