1

CSP SDO-450

Issue 3

(540) 427-3505

SDO-450

DYNAMIC OMNIDIRECTIONAL GOOSENECK MICROPHONE

INTRODUCTION

These instructions contain the specifications and

information necessary to install, operate, and

maintain the SDO-450 Dynamic Omnidirectional

Gooseneck Microphone.

SPECIFICATIONS

Applications

•Clarity Paging Systems

Features

•Dynamic element

•Omnidirectional pickup pattern

•Chrome screen with a black housing

•19” chrome gooseneck

•7 foot 4 conductor 2 shield cable permanently

attached

•Sealed push-button microswitch

•5/8” - 27 mounting thread

•Mounting flange included

Dimensions

•Microphone 1-38/”D x 4-5/8”L

•Gooseneck 19”L

Specifications

•ElementDynamic

•PatternOmnidirectional

•Freq. Response50 to 12K Hz

•Output ImpedanceLo Z 400 ohms

•Output LevelLo Z -58 db

(0db = 1 mw/10 microbars)

-152 db EIA

INSTALLATION

Refer to Figure 1 for connections to a Clarity

mixer-amplifier.

TECHNICAL ASSISTANCE

When trouble is reported, verify that there are no

broken connections leading to the microphone.

Assistance in troubleshooting is available from the

factory. When calling, you should have a VOM

available and be calling from the job site. Call

(540) 427-3505 and ask for an Applications

Engineer.

CLARITY equipment is not field repairable.

CLARITY maintains service facilities in Roanoke,

VA. Should repairs be necessary please call

CLARITY at (540) 427-3505 for a Return

Authorization Number.
