Citizen CL-S700II Handleiding

Citizen Labelprinter CL-S700II

Bekijk gratis de handleiding van Citizen CL-S700II (80 pagina’s), behorend tot de categorie Labelprinter. Deze gids werd als nuttig beoordeeld door 13 mensen en kreeg gemiddeld 3.5 sterren uit 7 reviews. Heb je een vraag over Citizen CL-S700II of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/80

CL-S700 Series

Thermal Transfer Barcode & Label Printer

USER'S MANUAL

CL-S700

CL-S703 CL-S700R

CONTENTS

Before Operation

INTRODUCTION -------------------------------------------------------------------- 3

COMPLIANCE STATEMENT FOR EUROPEAN USERS----------------------------- 4

GS MARK STATEMENT -------------------------------------------------------------- 4

FCC COMPLIANCE STATEMENT FOR AMERICAN USERS ----------------------- 4

EMI COMPLIANCE STATEMENT FOR CANADIAN USERS------------------------ 5

ETAT DE CONFORMITE EMI A L’USAGE DES UTILISATEURS CANADIENS ----- 5

IMPORTANT SAFETY INSTRUCTIONS--------------------------------------------- 6

NOTICE ------------------------------------------------------------------------------- 7

SAFETY INSTRUCTIONS ------------------------------------------------------------ 8

Chapter 1 Setup

Confirmation of Carton Contents -------------------------------------------------10

Part Names and Functions---------------------------------------------------------- 11

Connection to Power ---------------------------------------------------------------18

Driver Installation -------------------------------------------------------------------18

Connection to a Computer --------------------------------------------------------19

Chapter 2 Printer Operation

Power ON/OFF --------------------------------------------------------------------- 20

Normal Operating Mode ---------------------------------------------------------- 21

Setting the Media ------------------------------------------------------------------ 23

Setting the Ribbon ----------------------------------------------------------------- 32

Mode Settings ---------------------------------------------------------------------- 35

Quick Setup of the Print Method ------------------------------------------------- 51

Emulation Auto-Detection -------------------------------------------------------- 52

Setting the menu for the Rewinder (CL-S700R only) --------------------------- 53

Chapter 3 Printer Adjustments

Sensor Adjustments and Calibration --------------------------------------------- 54

Media Thickness Adjustment ----------------------------------------------------- 57

Media Width Adjustment ---------------------------------------------------------- 58

Adjusting the Ribbon -------------------------------------------------------------- 59

Moving the Adjustable Sensor ---------------------------------------------------- 61

Cleaning ---------------------------------------------------------------------------- 62

Chapter 4 Tr oubleshooting --------------------- 64

Appendixes

Specifications ---------------------------------------------------------------------- 66

Interfaces --------------------------------------------------------------------------- 70

Replacing the Interface Board ---------------------------------------------------- 76

Product specificaties

Merk:	Citizen
Categorie:	Labelprinter
Model:	CL-S700II
Soort bediening:	Knoppen
Kleur van het product:	Grijs
Gewicht:	13300 g
Breedte:	255 mm
Diepte:	490 mm
Hoogte:	265 mm
Kleur:	Nee
Beeldscherm:	LCD
USB-poort:	Ja
Connectiviteitstechnologie:	Bedraad
Ethernet LAN:	Nee
Aantal USB 2.0-poorten:	1
RS-232 port:	1
Duurzaamheidscertificaten:	ENERGY STAR
Ondersteunt Windows:	Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP
Ondersteunt Mac-besturingssysteem:	Ja
Ondersteunt Linux:	Ja
Flash memory:	16 MB
Maximale resolutie:	203 x 203 DPI
Mediadikte:	0.25 mm
Maximum roll diameter:	200 mm
Printtechnologie:	Direct thermisch/Thermische overdracht
Paginabeschrijving talen:	Datamax, EPL2, ZPL II
Ondersteunde server operating systems:	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012
Maximale print breedte:	104 mm
Printsnelheid (metrisch):	254 mm/sec
Parallelle poort(en):	1
Wifi:	Nee
Ondersteunde papierwijdte:	25 - 118 mm
Core diameter:	25 mm
Autocutter:	Ja
