Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.

Catalog No. 04-53300257-01Printed in U.S.A.Form No. 30HX-18SI Rev. APg 1 12-23Replaces: NEW

Instructions for Carrier Controller Retrofit Kit

30HX70000801

CONTENTS

Page

SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . .1

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

REQUIRED ITEMS . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

RETROFIT INSTRUCTIONS . . . . . . . . . . . . . . . . . . . .2

Step 1 — Remove Power . . . . . . . . . . . . . . . . . . . . . .2

Step 2 — Remove Boards . . . . . . . . . . . . . . . . . . . . .2

Step 3 — Drill New Holes . . . . . . . . . . . . . . . . . . . . . .2

Step 4 — Mount Boards . . . . . . . . . . . . . . . . . . . . . . .5

Step 5 — Connect Harnesses and Wiring . . . . . . . .7

Step 6 — Replace the Panel Assembly . . . . . . . . . . .8

Step 7 — Install Remote Connectivity Assembly . .8

APPENDIX A — CARRIER CONTROLLER SYSTEM

MENU STRUCTURE . . . . . . . . . . . . . . . . . . . . . . .13

APPENDIX B — 30HXC UNIT CONFIGURATION . .41

SAFETY CONSIDERATIONS

Installation and servicing of air-conditioning equipment can be

hazardous due to system pressure and electrical components. Only

trained and qualified service personnel should install, repair, or

service air-conditioning equipment.

Untrained personnel can perform basic maintenance functions of

cleaning coils and filters and replacing filters. All other operations

should be performed by trained service personnel. When working

on air-conditioning equipment, observe precautions in the

literature, tags and labels attached to the unit, and other safety

precautions that may apply.

Follow all safety codes. Wear safety glasses and work gloves. It is

important to recognize safety information. This is the safety-alert

symbol . When you see this symbol on the unit and in

instructions or manuals, be alert to the potential for personal

injury.

Understand the signal words DANGER, WARNING, CAUTION,

and NOTE. These words are used with the safety-alert symbol.

DANGER identifies the most serious hazards which will result in

severe personal injury or death. WARNING signifies hazards

which could result in personal injury or death. CAUTION is used

to identify unsafe practices, which may result in minor personal

injury or product and property damage. NOTE is used to highlight

suggestions which will result in enhanced installation, reliability,

or operation.

INTRODUCTION

This document is to be used in conjunction with the 30HX Instal-

lation Instructions as a supplement. It provides specific informa-

tion and instruction for the retrofitting of series 6 and later

ComfortLink controls to Carrier controls.

REQUIRED ITEMS

You will need the following items:

•Safety glasses

•Gloves

•Power tool with drill

•1/16 in. (.0625 in.) drill bit

•11/64 in. (.164 in.) drill bit

•30HX Carrier Controller Retrofit Kit P/N 30HX70000801.

See Table 1 for kit contents and part numbers

WARNING

This product can expose you to chemicals including lead and

lead components, which are known to the State of California

to cause cancer and birth defects or other reproductive harm.

For more information, go to www.P65Warnings.ca.gov.

WARNING

Electrical shock can cause personal injury and death. Shut off

all power to this equipment during installation and service.

There may be more than one disconnect switch. Tag all

disconnect locations to alert others not to restore power until

work is completed.

CAUTION

UNIT DAMAGE HAZARD

This unit uses a microprocessor-based electronic control sys-

tem. Do not use jumpers or other tools to short out components

or to bypass or otherwise depart from recommended proce

-

dures. Any short-to-ground of the control board or accompa-

nying wiring may destroy the electronic modules or electrical

components.

30HXC

Carrier Controller Retrofit

ComfortLink Series 6 and Later
