INSTALLATION INSTRUCTIONS

DURA

®

SPOT FILTER

INTERCHANGEABLE LENSES FOR CAMEO DURA SPOT

DS 60, DS 100, DS 200, DS 400 SPOTLIGHTS

Product number:CLDS60FILTER55

Type:55° interchangeable lens for DS60

Material:Plastic

Dimensions (Ø x height):79 x 1,5 mm

Weight:0.03 kg

Product number:CLDS60FILTER6010

Type:60° x10° interchangeable lens for DS60

Material:Plastic

Dimensions (Ø x height):79 x 1,5 mm

Weight:0.03 kg

Product number:CLDS100FILTER20

Type:20° interchangeable lens for DS100

Material:Plastic

Dimensions (Ø x height):115 x 1,5 mm

Weight:0.08 kg

Product number:CLDS100FILTER40

Type:40° interchangeable lens for DS100

Material:Plastic

Dimensions (Ø x height):115 x 1,5 mm

Weight:0.08 kg

Product number:CLDS100FILTER55

Type:55° interchangeable lens for DS100

Material:Plastic

Dimensions (Ø x height):115 x 1,5 mm

Weight:0.08 kg

Product number:CLDS100FILTER6010

Type:60° x 10° interchangeable lens for DS100

Material:Plastic

Dimensions (Ø x height):115 x 1,5 mm

Weight:0.08 kg

Product number:CLDS200FILTER20

Type:20° interchangeable lens for DS200

Material:Plastic

Dimensions (Ø x height):140 x 1,5 mm

Weight:0.12 kg

Product number:CLDS200FILTER40

Type:40° interchangeable lens for DS200

Material:Plastic

Dimensions (Ø x height):140 x 1,5 mm

Weight:0.12 kg

PRODUCT INFORMATION

This item is a product-specific accessory intended exclusively for use with Cameo Dura Spot

series spotlights.

These installation instructions do not replace the user manual of the associated product. Always

read the user manual first. This accessory has no influence on the intended use of the associated

product. Observe the safety instructions in the user manual of the associated product! The techni-

cal specifications stated in the user manual may change in connection with this accessory.

SAFETY INSTRUCTIONS

1. Please read this manual carefully.

2. Keep all information and instructions in a safe place.

3. Follow the instructions.

4. Use the accessory in the prescribed manner only.

DANGER: KEEP AWAY FROM CHILDREN! THE PRODUCT CONTAINS SMALL PARTS THAT CAN BE

SWALLOWED AS WELL AS PACKAGING MATERIAL THAT CAN BE SWALLOWED! PLASTIC BAGS

MUST BE KEPT OUT OF THE REACH OF CHILDREN!

PACKAGING CONTENT

Remove the product from the packaging and remove all packaging material. Please check the

completeness and integrity of the delivery and notify your distribution partner immediately after

purchase if the delivery is not complete or if it is damaged. Each product includes the correspon-

ding glare shield and installation instructions.

INSTALLATION

Remove the Phillips screws (see markings) from the mounting ring for the interchangeable lenses

and remove the ring from the glare shield of the spotlight (pictured: DS 100). Place the lens with

the textured side facing the lamp on the glare shield and then place the mounting ring over it whi-

le ensuring that the mounting holes of the lens and ring are exactly aligned with the screw holes

in the spotlight. Now attach the lens and ring to the glare shield using the previously removed

Phillips screws.

- Illustrations similar -

- Spotlight and mounting ring not included -

TECHNICAL SPECIFICATIONS

Product number:CLDS60FILTER20

Type:20° interchangeable lens for DS60

Material:Plastic

Dimensions (Ø x height):79 x 1,5 mm

Weight:0.03 kg

Product number:CLDS60FILTER40

Type:40° interchangeable lens for DS60

Material:Plastic

Dimensions (Ø x height):79 x 1,5 mm

Weight:0.03 kg
