Bekijk gratis de handleiding van Cadel Kook 90 (36 pagina’s), behorend tot de categorie Fornuis. Deze gids werd als nuttig beoordeeld door 12 mensen en kreeg gemiddeld 4.6 sterren uit 6.5 reviews. Heb je een vraag over Cadel Kook 90 of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/36

INSTALLER MANUAL

Wood Coocking Stove

KOOK 60 - KOOK 80- KOOK 90

SMART 60 - SMART 80 - FRIDA 80

KOOK60 - KOOK80 - KOOK90 - SMART60 - SMART80 - FRIDA 80

SUMMARY

1 MANUAL SIMBOLOGY ....................................3

2 PACKAGING AND HANDLINGPACKAGING AND

HANDLING .........................................................3

2.1 PACKAGING .............................................................3

2.2 REMOVING THE STOVE FROM THE PALLET ..............3

2.3 STOVE HANDLING....................................................4

3 CHIMNEY FLUE .............................................4

3.1 PREPARING THE SMOKE EXPULSION SYSTEM .........4

3.2 CHIMNEY COMPONENTS .........................................4

3.3 SMOKE DUCT (SMOKE FITTING) ..............................5

3.4 FLUE (CHIMNEY OR PIPED DUCT) ...........................5

3.5 CHIMNEY POT ..........................................................6

3.6 MAINTENANCE ........................................................6

4 COMBUSTION AIR .........................................7

4.1 AIR INLET ................................................................7

5 EXAMPLES OF CORRECT INSTALLATION ..........8

6 INSTALLATION ..............................................9

6.1 INTRODUCTION .......................................................9

6.2 OVERALL DIMENSIONS .........................................10

6.3 GENERAL INSTALLATION ....................................... 13

6.4 LEVELLING KOOK 60 .............................................. 15

6.5 LEVELLING KOOK 80 - KOOK 90 - SMART 60 - SMART

80 ..............................................................................15

6.6 ASSEMBLY OF DOOR HINGED TO LEFT KOOK 60 ....16

6.7 ELECTRIC CONNECTION .........................................18

6.8 REMOVING THE STAINLESS STEEL PLINTH (KOOK 80 -

KOOK 90 - SMART 60 - SMART 80) ...................................18

6.9 MOUNTING THE METAL SIDE PANELS (KOOK - SMART

- FRIDA) ...........................................................................19

6.10 SMART 60 - SMART 80 FEET ASSEMBLY ................19

6.11 MOUNTING THE FLUE GAS EXHAUST STUB PIPE ...20

7 MAINTEINANCE ..........................................21

7.1 INTRODUCTION .....................................................21

7.2 FUME PASSAGES CLEANING KOOK 60 ...................21

7.3 FUME PASSAGES CLEANING KOOK 90 - KOOK 80 -

SMART 80 (KOOK 87) .......................................................22

7.4 CLEANING THE SIDE FLUE GAS PASS .....................22

7.5 FANS CLEANING ....................................................23

7.6 REPLACING THE FAN..............................................23

7.7 GASKET REPLACEMENT ......................................... 23

7.8 OVEN LIGHT REPLACEMENT .................................. 23

7.9 HEART BREAK KOOK 60 .........................................24

7.10 HEART BREAK (KOOK 80 - 90) (SMART 60 - 80) (FRIDA

80) VALID FROM 2021 ...................................................... 25

7.11 REPLACING THE STAINLESS STEEL TOP .................26

7.12 REPLACING THE DOORS ......................................... 26

8 IN CASE OF ANOMALY ..................................27

8.1 PROBLEM SOLVING ...............................................27

9 TECHNICAL DATAS ......................................28

9.1 WIRING SCHEME ...................................................28

9.2 FEATURES ..............................................................29

Product specificaties

Merk:	Cadel
Categorie:	Fornuis
Model:	Kook 90
Apparaatplaatsing:	Vrijstaand
Kleur van het product:	Anthracite, Stainless steel
Gewicht:	128000 g
Breedte:	900 mm
Diepte:	600 mm
Hoogte:	855 mm
Gewicht verpakking:	138000 g
Uitlaat aansluiting diameter:	140 mm
Aantal branders/kookzones:	- zone(s)
Voedingsbron oven:	Electrisch
Aantal ovens:	1
Met oven:	Ja
Stroombron:	AC
Vermogen:	7500 W
Energieverbruik (conventioneel):	- kWu
Uitlaat locatie:	Boven
Ovenpositie:	Rechtsonder
Brutocapaciteit oven:	- l
Vermogensverbruik (max):	60 W
Meegeleverde haardplaat:	Ja
AC-ingangsspanning:	230 V
AC-ingangsfrequentie:	50 Hz
Type product:	Vrijstaand fornuis
Binnenmaten oven (b x d x h):	330 x 420 x 290 mm
Geschikt voor ruimtevolume tot:	180 m³
Brandstof:	Kaphout
Oven afmetingen:	330 x 420 x 290 mm
Brandhout inname:	2.2 kg/h
Koolstofmonoxideniveau (CO) (nominaal):	0.07 procent
Rendement (nominaal):	82.5 procent
