Braeburn 1220NC Handleiding

Bekijk gratis de handleiding van Braeburn 1220NC (10 pagina’s), behorend tot de categorie Niet gecategoriseerd. Deze gids werd als nuttig beoordeeld door 10 mensen en kreeg gemiddeld 4.1 sterren uit 6 reviews. Heb je een vraag over Braeburn 1220NC of wil je andere gebruikers van dit product iets vragen? Stel een vraag

This thermostat requires 24 Volt AC Power or two (2) properly installed

“AA” Alkaline batteries for proper operation. When connecting 24 Volt

AC Power the batteries may be installed as a backup.

For use only as described in this manual. Any other use

will void warranty.

1020NC

Single Stage Heat / Cool

Conventional and Heat Pump

1

Specifications

2

About Your Thermostat

3

Installation

4

System Testing

5

Setting User Options

6

Operating Your Thermostat

7

Additional Operation Features

8

Thermostat Maintenance

®

Warning

Turn off power to the heating or cooling

equipment before installation.

Attention

For installation by experienced service

technicians only.

1220NC

Up to 2 Heat / 1 Cool

Conventional and Heat Pump

Read all instructions before proceeding.

This thermostat is compatible with:

•Singlestageheat/coolconventionalandheatpumpsystems

•Conventionalsystemsupto2heat/1cool(1220NConly)

•Singlecompressorheatpumpsystemswithanauxiliaryheatstage(1220NConly)

•250–750millivoltheatonlysystems

Electrical and control specifications:

•ElectricalRating:24VoltAC

•1ampmaximumloadperterminal

•ACPower:18–30VoltsAC

•DCPower:3.0VoltDC(2“AA”AlkalineBatteriesIncluded)

•ControlRange:45°–90°F(7°–32°C)

•TemperatureAccuracy:+/-1°F(+/-.5°C)

Terminations

•1020NC–Rc,Rh,O,B,Y1,W1,G,C

•1220NC–Rc,Rh,O,B,Y1,E/W1,G,W2,C

1

Specifications

1020NCW-100-03

Non-Programmable

Thermostats

Model number is located on back of thermostat

Detailed

Installer Guide

Product specificaties
