AutoDome Camera Quick Guide

All AutoDome 100, 200, 300 and 500i Series cameras

are available in In-Ceiling, Indoor Pendant and

Outdoor Pendant style housings.

Standard Features

AutoDome 100 Series

Fixed Dome Camera System

AutoDome 200 Series

PTZ Camera System

AutoDome 300 Series

Advanced PTZ Camera System

AutoDome 500i Series

Intelligent PTZ Camera System

Interchangeable CPU, Camera and Comms ModulesYesYesYesYes

Operating Temperature:

Indoor Housing-10°C to 50°C (14°F to 122°F)-10°C to 50°C (14°F to 122°F)-10°C to 50°C (14°F to 122°F)-10°C to 40°C (14°F to 104°F)

EnviroDome Outdoor Housing-55°C to 50°C (67°F to 122°F)-60°C to 50°C (-76°F to 122°F)-60°C to 50°C (-76°F to 122°F)-60°C to 50°C (-76°F to 122°F)

Protocol SupportN/ABosch Biphase, RS232 & 485, Pelco "P" or "D"Bosch Biphase, RS232 & 485, Pelco "P" or "D"Bosch Biphase, RS232 & 485, Pelco "P" or "D"

Up the wire control/configurationYes, BilinxYes, BilinxYes, BilinxYes, Bilinx

Privacy Masking/Sector BlankingNoNoYesYes

Pre-PositionsN/A649999

Guard TourN/A1 Preset Tour2 Preset Tours; 2 Recorded Tours2 Preset Tours; 2 Recorded Tours

Remote Fast AddressN/AYesYesYes

AutoPivot and AutoScalingN/AYesYesYes

Cable CompensationNoNoYesYes

Alarm Inputs/Relay Outputs

N/AN/A7/47/4

Warranty3 Years3 Years3 Years3 Years

CPUs

– Interchangeable Modules:

• Pluggable upgrade to 200, 300 or

500i Series CPU

• "Hot-Swap" camera replacement or upgrades

• Pluggable Communications Module

– Built-in Surge Suppression

– Interchangeable Modules

– Fast 360° per second pan/tilt speeds

– Advanced Troubleshooting and Diagnostics

• Diagnostic LEDs

• On-screen diagnostic displays

– Built-in Surge Suppression

Includes all of the features of the

200 Series plus:

– Superior Privacy Masking:

• 24 masks

• Up to 8 masks per scene

– Advanced alarm handling via "Rules" engine

Includes all the advanced features of the

300 Series plus:

– AutoTrack II

– Video Motion Detection

– “Virtual Masking” Technology

– Digital Image Stabilization

Cameras

Resolution540 TVL470 TVLup to 540 TVLup to 540 TVL

Sensitivity – Color Mode (30 IRE)

Day/Night: 0.29 lux

F1.4, 1/60 (1/50) shutter, max AGC

18x Color: 0.5 lux

F1.4, 1/60 (1/50) shutter, max AGC

26x Day/Night: 0.5 lux

F1.4, 1/60 (1/50) shutter, max AGC

36x Day/Night: 0.6 lux

F1.6, 1/60 (1/50) shutter, max AGC

Sensitivity – Night Mode (30 IRE)

Day/Night: 0.12 lux

F1.4, 1/60 (1/50) shutter, max AGC

N/A

26x Day/Night: 0.1 lux

F1.4, 1/60 (1/50) shutter, max AGC

36x Day/Night: 0.16 lux

F1.6, 1/60 (1/50) shutter, max AGC

Day/NightYesNoYesYes

Lens

2.7mm to 13.5mm, f/1.2

5mm to 50mm, f/1.4

4.1mm to 73.8mm, f/1.4

4.1mm to 73.8mm, f/1.4

3.5mm to 91.0mm, f/1.6

3.4mm to 122.4mm, f/1.6

4.1mm to 73.8mm, f/1.4

3.5mm to 91.0mm, f/1.6

3.4mm to 122.4mm, f/1.6

Optical Zoom

5x (Varifocal)

10x (Varifocal)

18x

18x

26x

36x

18x

26x

36x

Digital ZoomNoNo

12x12x

Housings

IndoorIn-Ceiling, PendantIn-Ceiling, PendantIn-Ceiling, PendantIn-Ceiling, Pendant

OutdoorPendantPendantPendantPendant

Ingress Protection

IP66/NEMA 4X (Pendant Housings)

IP54 (In-Ceiling Housings)

IP66/NEMA 4X (Pendant Housings)

IP54 (In-Ceiling Housings)

IP66/NEMA 4X (Pendant Housings)

IP54 (In-Ceiling Housings)

IP66/NEMA 4X (Pendant Housings)

IP54 (In-Ceiling Housings)

Communications

Coax/UTPBilinx, UTP, CoaxBilinx, UTP, CoaxBilinx, UTP, CoaxBilinx, UTP, Coax

Optional Ethernet (TCP/IP)Cat5/Cat6 (UTP)Cat5/Cat6 (UTP)Cat5/Cat6 (UTP)Cat5/Cat6 (UTP)

Power Supplies/Mounts

Power Supplies:

24VACYesYesYesYes

120V, 230VACYesYesYesYes

Indoor MountsWall, Pipe, In-CeilingWall, Pipe, In-CeilingWall, Pipe, In-CeilingWall, Pipe, In-Ceiling

Outdoor MountsWall, Corner, Mast, Pipe, Flat Roof, Roof (Parapet)Wall, Corner, Mast, Pipe, Flat Roof, Roof (Parapet)Wall, Corner, Mast, Pipe, Flat Roof, Roof (Parapet)Wall, Corner, Mast, Pipe, Flat Roof, Roof (Parapet)

Fiber Optics

Optional Bi-directional Analog Fiber Transceiver

(video and control over a single fiber)

YesYesYesYes
