AMF42AU QUICK REFERENCE GUIDE

Contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk

AMF42AU

Quick Reference Guide

01

Our AMF42AU is an advanced 4K 4x2 multi-format presentation switcher featuring

3 x HDMI and 1 x USB-C input to 2 x HDMI / 1 x HDBaseT™ output. The AMF42AU

provides enhanced features including seamless switching, independent video

scaling on outputs, MIC input with phantom power, audio mixing and PoC to

power a Blustream compatible HDBaseT™ receiver. The AMF42AU also features

a Web GUI for control and configuration, source and display control via: RS-232,

CEC, manual or automated source selection, IR pass-through and control via front

panel, IR, RS-232 and TCP/IP. The AMF42AU is an ideal product for your boardroom,

classroom or lecture theatre.

Introduction

FEATURES:

• Features 3 x HDMI and 1x USB-C inputs which can be independently routed to 2 x HDMI / HDBaseT™ outputs

• Seamless source switching with manual or auto source selection

• Independent video scaling on dual outputs

• Supports HDMI 2.0 18Gbps specification

• Supports resolutions up to 4K UHD 60Hz 4:4:4

• Dual HDMI / HDBaseT™ on output 2. HDBaseT™ output supports distribution of video sources up to 70m 1080p (4K

60Hz 4:4:4 up to 40m) to the Blustream RX70CS receiver

• Supports USB Type C up to 4K UHD 60Hz 4:4:4, DP1.2 with 40W charging capability

• Audio breakout to analogue L/R audio and Toslink (S/PDIF) digital outputs concurrently

• Audio mixing capabilities with independent level adjustment

• Analogue audio inputs support both balanced and unbalanced audio

• MIC input supports line level or 48V phantom power

• Configurable source and display control via RS-232, IR and CEC

• Web interface module for control and configuration of matrix

• Control via TCP/IP, RS-232, IR and front panel

• Open control API (IP / RS-232) for integration with 3rd party control platforms

• HDCP 2.2 compliant with advanced EDID management
