Do not drop, knock or shake the unit
Do not disassemble or modify the unit
Keep the unit dry and away from all liquids
Avoid extreme temperatures
Clean with a soft dry microfibre cloth
Safety InstructionsIn the Box
B3 Main Unit
Bluetooth Antenna
USB C Cable
TOSLNIK Cable
USB DAC with Bluetooth 5.1
Front View of B3
Back View of B3
Using the MFB (Multi Function Button)
Power ON/OFF: Press and hold the MFB for 3 seconds.
Un-pair connected Bluetooth devices: Double press the MFB.
Factory reset: Power OFF the blafili B3, then press and hold the MFB
for 10 seconds. DEVICES ERASED will be displayed on the OLED display.
OLED Display
XLR Output
Bluetooth Antenna
Multi Function Buton
(ON/OFF - BT Connection Reset - Factory Reset)
USB - C Input
(Power & Audio Input)
RCA Output
Coaxial Output
Optical (TOSLINK) Output
Basic Setup
Specifications
Attach the antenna to the back of the blafili B3
Choose and connect output (XLR/RCA/COAX/TOSLINK) to both the back of the blafili B3 and your home audio
device (HiFi amplifier for example).
Connect USB-C cable to a powered source (If you wish to transfer music to the blafili B3 via USB which will
produce the maximum sound quality, connect the USB-C cable to powered USB socket on your PC. If you
only wish to use the Bluetooth capability of the blafili B3, you can use a standard USB mobile phone charger
to power the unit.)
Unit will automatically power on.
Turn on home audio device.
(A) If using USB input, play your digital music file on your PC. Enjoy!
(B) To use Bluetooth mode, pair the blafili B3 with your preferred Bluetooth enabled device (for example
mobile phone). Play your music. Enjoy!
1.
2.
3.
4.
5.
6.
How many Bluetooth devices can this connect to at a single time?
Two Bluetooth source devices blafili B3 can connect to at a single time. However ONLY 1 can play at a time, you
have to pause the other.
Here is the guide of HOW TO PAIR TWO DEVICES:
1. Power on blafili B3 Bluetooth receiver.
2. Enable Bluetooth on the 1st device, search and connect to “blafili B3”.
3. After pairing successfully, disable Bluetooth on the 1st device. blafili B3 will enter pairing mode again.
4. Pair blafili B3 to the 2nd device by the same way.
5. After pairing successfully, enable Bluetooth on the 1st device, click to connect “blafili B3” again.
6. Now both 2 devices are connected to blafili B3.
Is there a master volume or gain?
There is no volume control included, but the source component connected will have volume control. The volume
control on the powered speakers also impacts the volume.
DC input: 5V, 0.5A (min)
Bluetooth chipset: Qualcomm QCC5125
DAC chipset: ES ES9018K2M
Bluetooth version: 5.1
Supported codecs: AAC, SBC, aptX, aptX LL, aptX HD, LDAC
Size: 141 x76 x38mm / 5.6 x3.0 x1.5in
Operating temperature range: -10degC to +55degC/14degF
to 131degF
Weight (without packaging): 240g/8.47oz
Range: 30m/100ft
Inputs: Bluetooth, USB-C
Outputs: XLR, RCA, TOSLINK, Coaxial
Output voltage: 2.1V RMS
Output impedance: 57ohms
Freq response: 10hz-20kHz(+/- 0.5dB)
DNR: +127dB
Latency: -30ms
THD+N: -120dB
DAC Output Resistance: 806ohm
Specifications are subject to change without notice.
When using USB mode to play music, you may need to select the blafili B3 as the preferred audio device in your operating system.
Bluetooth mode will automatically override USB mode if both are being used.
Please Note:
If you have any further queries please contact us on michaelw@blafili.com
Didn't hear sound out of the digital coaxial/optical output ?
1. Go to your device Settings.
2. Tap on System.
3. Navigate to Developer options (you may need to turn on the Developer options first).
4. Find the Bluetooth audio sample rate menu.
5. Select 44.1kHz/48kHz instead of 96kHz.
FAQs
