Bixolon XM7-40WK Handleiding

Bixolon Labelprinter XM7-40WK

Bekijk gratis de handleiding van Bixolon XM7-40WK (40 pagina’s), behorend tot de categorie Labelprinter. Deze gids werd als nuttig beoordeeld door 72 mensen en kreeg gemiddeld 4.7 sterren uit 36.5 reviews. Heb je een vraag over Bixolon XM7-40WK of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/40

User’s Manual

XM7-40 Series

MOBILE PRINTER

Ver. 1.04

http://www.bixolon.com

Ver. 1.04

- 2 -

XM7- Series 40

Table of Contents

Copyright .......................................................................................................................... 4

WARNING & CAUTION 7.....................................................................................................

Manual Introduction ......................................................................................................10

Product Introduction ...................................................................................................... 11

1. Preparation .................................................................................................................. 12

1-1 Components ....................................................................................................................12

1-2 Front Part Names ............................................................................................................ 13

1-3 Rear Part Names .............................................................................................................13

1-4 LCD Menu Names ............................................................................................................ 14

1-4-1 Top icon ...............................................................................................................14

1-4-2 Main menu icon .................................................................................................. 15

2. Installation & Connection ..........................................................................................17

2- Battery Installation 1 .......................................................................................................... 17

2-2 Battery Charging ............................................................................................................. 18

2-2-1 Using AC/DC Adapter ......................................................................................... 18

2-2-2 Using Single Battery Charger (Optional) ......................................................... 19

2-2-3 Using Quad Battery Charger (Optional) ..........................................................20

2-3 Media Installation ............................................................................................................ 22

2-4 Bluetooth & Wireless LAN Connection .........................................................................24

2-5 Interface Cable Connection ............................................................................................ 25

2-6 Fixed Interface Cable Connection .................................................................................26

3. Use ................................................................................................................................ 27

3-1 Using Peeler ..................................................................................................................... 27

3-2 Using Belt Strap ............................................................................................................... 28

3-3 Using Shoulder Strap (Optional) ................................................................................... 29

3-4 Using Fan-Fold Media ..................................................................................................... 30

3-4-1 Media Width 105 mm (4.13 inch) ...................................................................... 30

3-4-2 Media Width 112 mm (4.41 inch) ...................................................................... 30

3-4-3 Media Width 54~110 mm (2.13~3.94 inch) ....................................................... 30

3-4-4 Separate the Fan-Fold Cap .................................................................................31

3-5 Using Control Button ...................................................................................................... 32

3-5-1 Power Button ...................................................................................................... 32

3-5-2 Media Feed Button ............................................................................................. 32

3-5-3 Menu Move Button ............................................................................................. 32

3-5-4 Menu Select Button ............................................................................................ 32

4. RFID Transponder ........................................................................................................33

Ver. 1.04

- 3 -

XM7- Series 40

5. Self-Test ........................................................................................................................ 34

5-1 Self-Test Instructions ...................................................................................................... 34

5-2 Self-Test Sample .............................................................................................................. 35

6. Cleaning ....................................................................................................................... 37

7. Appendix ...................................................................................................................... 38

7-1 Printer Specifications ...................................................................................................... 38

7-2 Label Types Specifications .............................................................................................. 39

Product specificaties

Merk:	Bixolon
Categorie:	Labelprinter
Model:	XM7-40WK
Kleur van het product:	Zwart
Ingebouwd display:	Ja
Gewicht:	1090 g
Breedte:	158 mm
Diepte:	186 mm
Hoogte:	82 mm
Soort:	Mobiele printer
Internationale veiligheidscode (IP):	IP54
Ondersteunde mobiele besturingssystemen:	Android, iOS
Capaciteit van de accu/batterij:	6800 mAh
Resolutie:	240 x 320 Pixels
Wi-Fi-standaarden:	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
USB-poort:	Ja
Connectiviteitstechnologie:	Bedraad en draadloos
Ethernet LAN:	Nee
Type stroombron:	Batterij/Accu
Accu/Batterij voltage:	7.2 V
Soort serieële aansluiting:	RS-232
Intern geheugen:	128 MB
Opslagmedia:	Flash
Duurzaamheidscertificaten:	ENERGY STAR
Ondersteunde beveiligingsalgoritmen:	40-bit WEP, WPA2, 104-bit WEP, WPA
Ondersteunt Windows:	Ja
Temperatuur bij opslag:	-30 - 70 °C
Mac-compatibiliteit:	Ja
Ondersteunt Linux:	Ja
Flash memory:	256 MB
Maximale resolutie:	203 x 203 DPI
Mediadikte:	0.07 ± 0.15 mm
Maximum roll diameter:	66 mm
USB-connector:	USB Type-C
Printtechnologie:	Direct thermisch
Paginabeschrijving talen:	CPCL-native, ZPL II
Meegeleverde drivers:	Ja
Kleurenscherm:	Nee
Maximale print breedte:	104 mm
Printsnelheid (metrisch):	127 mm/sec
Wifi:	Ja
Bedrijfstemperatuur (T-T):	-15 - 50 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 80 procent
Batterijtechnologie:	Lithium-Ion (Li-Ion)
Type beeldscherm:	LCD
Code geharmoniseerd systeem (HS):	84433210
Ondersteunde papierwijdte:	50 - 112 mm
Seriële interface:	Ja
Character sets:	16 BPL-Z, SLCS
Print snelheid:	5 ips
Afdrukbare dot-nummers:	8 dot
