LAKEWOOD
SWING SET
MODEL: # 2001022
EASY STEP-BY-STEP
3D INTERACTIVE INSTRUCTIONS
DOWNLOAD THE FREE APP
WARNING
Adult Assembly Required.
The assembly manual must be retained since it contains important information
Not suitable for children under 36 months due to small parts.
FOR DOMESTIC USE ONLY. INTENDED FOR OUTDOOR USE.
Important Assembly Notes
1) While assembling unit, take time before and after each step to make sure fort is level. If fort is
not level, assembly will be difficult and improper assembly may result. Extra care must be taken to
insure the fort is square.
2) Tighten bolts securely, tighten nuts on bolts flush to the tube or member, and place caps over
exposed bolts snug to the nut.
3) Pay close attention to the ITEMS NEEDED FOR EACH STEP. They can be a valuable aid when
sorting your wood and hardware. Assembly will be made easier if items are sorted by step.
4) Pay close attention to make sure you are using the correct hardware in the correct steps. Using
incorrect hardware may result in improper assembly.
5) Whenever a T-nut is used, follow these directions. Place T-nut in pre-drilled hole. Tap in with hammer.
Place bolt with washers in the opposite side. Hand tighten to make sure the bolt is in the T-nut.
DO NOT over tighten.
6) Read the order of each step thoroughly. The written steps may include important information not
shown in the illustrations.
Basic Setup Dimensions
Place the set on level ground, not less than 6 ft-7 in [2 m] from any structure or obstruction such
as a fence, garage, house, overhanging branches, laundry lines, or electrical wires.
Safe Play Zone
Safe play height: 14'-7" [4.4 m]
Maximu
m fall height: 6'-3 1/2" [1.9 m]
General Information:
Your set has been designed and engineered for
children only and for residential use only.
A maximum of 150 lbs. per child is recommended for
play activities designed for individual use.
A maximum of 120 lbs. per child is recommended for
play activities designed for multiple child use.
A maximum of 9 children is recommended for this
swing set.
11'-3"
[3.4 m]
14'- 1/2"
[4.3 m]
24'-5"
[7.4 m]
27'-2 1/2"
[8.3 m]
6'-7"
[2 m]
6'-7"
[2 m]
6'-3 1/2"
[1.9 m]
8'-7"
[2.6 m]
