Axxess AX-LOC2.2 Handleiding

Bekijk gratis de handleiding van Axxess AX-LOC2.2 (12 pagina’s), behorend tot de categorie Niet gecategoriseerd. Deze gids werd als nuttig beoordeeld door 23 mensen en kreeg gemiddeld 4.7 sterren uit 3 reviews. Heb je een vraag over Axxess AX-LOC2.2 of wil je andere gebruikers van dit product iets vragen? Stel een vraag

AX-LOC2.2 & AX-LOC2.4

INSTALLATION INSTRUCTIONS

MetraOnline.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 5/8/23 INSTAX-LOC2.2 & AX-LOC2.4

TABLE OF CONTENTS

Quick Start Guide

Things to Know .................................................2

Connections .......................................................2

Gain setup

Basic setup .........................................................3

Advanced Setup ................................................3

Feature Breakdowns .............................................4

Quick Reference: AX-LOC2.2 ..................................5

Diagram: AX-LOC2.2...............................................6

Quick Reference: AX-LOC2.4 .................................7

Diagram: AX-LOC2.4 ..............................................8

Specifications .........................................................9

Universal Premium LOC

AX-LOC2.22 IN - 2 OUT with Max Input 20v

AX-LOC2.4 2 IN - 4 OUT with Max Input 20v

TOOLS RECOMMENDED

• Digital Multi-meter

• Test Tones

Universal Premium LOCs

The Axxess AX-LOC2.2 & AX-LOC2.4 can be used to add amplifiers to an audio system that does not have RCA outputs or when replacing an OEM

radio and retaining the factory amplified system. Variable Gain Controls with Clipping Indicators, Selectable Ground Isolation and Load Select

features ensure a pure, noise-free signal for any type of audio system.

AX-L0C2.4

AX-LOC2.4

Line Out Converter (LOC)

COMPONENTS

AX-L0C2.2

AX-LOC2.2

Line Out Converter (LOC)
