AX-ALOC700AX-ALOC700AX-ALOC700

INSTALLATION INSTRUCTIONSINSTALLATIONINSTRUCTIONSINSTALLATIONINSTRUCTIONS

REV. 1/15/18REV. 1/15/18REV. 1/15/18© COPYRIGHT 2018 METRA ELECTRONICS CORPORATION © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION

Integrate • AxxessInterfaces.comIntegrate • AxxessInterfaces.comIntegrate • AxxessInterfaces.com

Wire Color & Function: The audio input wire colors are an EIA standard

for car stereo applications as follows.

INPUT HARNESS

White = Left front (+) input

White/Black = Left front (-) input

Gray = Right front (+) input

Gray/Black = Right front (-) input

Brown = Reference ground (-)

(Reference ground optional if noise is present)

Note:

Be sure that all audio input connections are polarized or in phase

with each other. That is, the positive output wires from the audio source

need to be connected to the corresponding positive input wires of the

AX-ALOC700. The same goes for the negative audio wires. Failure to do

this will result in poor bass response and low quality audio.

Adjusting the AX-ALOC700 for maximum performance:After completing

all of the necessary connections, turn the AX-ALOC700 adjustment pots

all of the way down by rotating them completely counter-clockwise.

Now, turn the stereo system on and adjust the main volume control on

the stereo to approximately 3/4 maximum volume. Select one of the

adjustment pots on the AX-ALOC700 and turn it slowly clockwise until

you notice audio distortion and then stop. Turn the remaining pot to the

same position as the previously adjusted pot. The audio set-up of the

AX-ALOC700 is now complete and ready to be enjoyed.

Wire Color & Function:The audio input wire colors are an EIA standard

for car stereo applications as follows.

INPUT HARNESS

White= Left front (+) input

White/Black= Left front (-) input

Gray= Right front (+) input

Gray/Black= Right front (-) input

Brown= Reference ground (-)

(Reference ground optional if noise is present)

Note:

Be sure that all audio input connections are polarized or in phase

with each other. That is, the positive output wires from the audio source

need to be connected to the corresponding positive input wires of the

AX-ALOC700. The same goes for the negative audio wires. Failure to do

this will result in poor bass response and low quality audio.

Adjusting the AX-ALOC700 for maximum performance:After completing

all of the necessary connections, turn the AX-ALOC700 adjustment pots

all of the way down by rotating them completely counter-clockwise.

Now, turn the stereo system on and adjust the main volume control on

the stereo to approximately 3/4 maximum volume. Select one of the

adjustment pots on the AX-ALOC700 and turn it slowly clockwise until

you notice audio distortion and then stop. Turn the remaining pot to the

same position as the previously adjusted pot. The audio set-up of the

AX-ALOC700 is now complete and ready to be enjoyed.

Wire Color & Function:The audio input wire colors are an EIA standard

for car stereo applications as follows.

INPUT HARNESS

White= Left front (+) input

White/Black= Left front (-) input

Gray= Right front (+) input

Gray/Black= Right front (-) input

Brown= Reference ground (-)

(Reference ground optional if noise is present)

Note:

Be sure that all audio input connections are polarized or in phase

with each other. That is, the positive output wires from the audio source

need to be connected to the corresponding positive input wires of the

AX-ALOC700. The same goes for the negative audio wires. Failure to do

this will result in poor bass response and low quality audio.

Adjusting the AX-ALOC700 for maximum performance:After completing

all of the necessary connections, turn the AX-ALOC700 adjustment pots

all of the way down by rotating them completely counter-clockwise.

Now, turn the stereo system on and adjust the main volume control on

the stereo to approximately 3/4 maximum volume. Select one of the

adjustment pots on the AX-ALOC700 and turn it slowly clockwise until

you notice audio distortion and then stop. Turn the remaining pot to the

same position as the previously adjusted pot. The audio set-up of the

AX-ALOC700 is now complete and ready to be enjoyed.

The AX-ALOC700 is designed to convert speaker level audio to line level

audio. This allows for the installation of line level products such as amplifiers,

EQs and crossovers on systems that do not have RCA line level outputs.

Features:

80 Watts Maximum Input, Input Circuit Corrects Crossover Distortion

Commonly Found On Other Brands of LOCs, 6:1 Step Down with

Variable Output, Detachable Input Plug, Gold Plated RCAs, Attractive &

Durable Enclosure

The AX-ALOC700is designed to convert speaker level audio to line level

audio. This allows for the installation of line level products such as amplifiers,

EQs and crossovers on systems that do not have RCA line level outputs.

Features:

80 Watts Maximum Input, Input Circuit Corrects Crossover Distortion

Commonly Found On Other Brands of LOCs, 6:1 Step Down with

Variable Output, Detachable Input Plug, Gold Plated RCAs, Attractive &

Durable Enclosure

The AX-ALOC700is designed to convert speaker level audio to line level

audio. This allows for the installation of line level products such as amplifiers,

EQs and crossovers on systems that do not have RCA line level outputs.

Features:

80 Watts Maximum Input, Input Circuit Corrects Crossover Distortion

Commonly Found On Other Brands of LOCs, 6:1 Step Down with

Variable Output, Detachable Input Plug, Gold Plated RCAs, Attractive &

Durable Enclosure

2 Channel, Adjustable Line Output Converter2 Channel, Adjustable Line Output Converter2 Channel, Adjustable Line Output Converter
