Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 6/10/24 INST95-6558B
INSTALLATION INSTRUCTIONS
95-6558B
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product.
Ensure that all installation connections,
especially the air bag indicator lights, are
plugged in before reconnecting the battery
or cycling the ignition to test this product.
NOTE: Refer also to the instructions included
with the aftermarket accessory before
installing this device.
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Display screen and button assembly • D) #8 x 1/2” Phillips screws (4) • E) Panel clips (4)
• F) Interface buttons: blanks (5) and with graphics (5) (not shown)
KIT FEATURES
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• 9/32" socket wrench • T-20 Torx driver
TABLE OF CONTENTS
Dash Disassembly .............................................. 2-3
Kit Preparation ...................................................4-6
Kit Assembly ..........................................................7
Axxess Interface Installation ...........................8-18
WIRING & ANTENNA CONNECTIONS
Wiring Harness: Axxess interface built
into display creen
Antenna Adapter: Included with kit
A B C
D
E
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle
specific applications
Ram 1500/2500/3500, Chassis Cab
3500/4500/5500 (with 8.4" touchscreen) 2013-2018
Ram Classic 1500 (with 8.4" touchscreen) 2019-2022
• ISO DDIN radio provision
• Retains factory climate control buttons and
adds buttons for lost functions with access
to vehicle personalization menus
• Built in OLED screen displays visual status
of climate functions such as temperature,
fan speed, and vent mode that were
displayed on the factory screen
• All in one interface to retain climate control
functions, factory amplifier, and steering
wheel controls
• Painted scratch resistant matte black with
chrome accents
Trailer brake control system not retained
386.257.1187
|
MetraOnline.com
DASH DISASSEMBLY
2
1. Remove the rubber tray liner inside the
tray at the top center of the dash, then
remove (2) Torx T-20 screws exposed.
(Figure A)
2. Remove the rubber tray liner from inside
the small pocket on the passenger side
of the center dash panel, then remove
(1) Torx T-20 screw exposed. (Figure B)
(Figure C)
3. For models with a center console:
a. Remove the rubber liner from the
storage tray in front of the center
console, then remove (2) Phillips
screws exposed. (Figure C)
b. Remove the rubber liner from the
middle of the center console, then
remove (1) Phillips screw exposed.
(Figure C)
c. Remove the rubber liner from the
rear of the center console, then
remove (2) Phillips screws exposed.
(Figure C)
d. Unsnap and remove the top of the
center console.
Continued on the next page
(Figure B)
(Figure A)
