Installation Guide

AT-HDVS-CAM-HDBT-BK and AT-HDVS-CAM-HDBT-WH

PTZ Camera with HDBaseT Output

AT-HDVS-CAM-HDBT-BK and AT-HDVS-CAM-HDBT-WH

The Atlona AT-HDVS-CAM-HDBT is an enterprise-grade PTZ camera designed for use in

video conferencing and other applications such as lecture capture and distance education. It

features an HDBaseT output for extending video, power, and camera control over distances up

to 330 feet (100 meters). The HDVS-CAM-HDBT is ideal for remotely interfacing into HDBaseT

equipped switchers and extenders, for use with a video conferencing codec, lecture capture

appliance, or PC equipped for video capture. Camera control over HDBaseT or TCP/IP facilitates

remote integration into AV control systems. The HDVS-CAM-HDBT delivers high performance,

professional-quality imaging with video resolutions up to 1080p @ 60 Hz, as well as fast and

accurate auto-focusing, and a fast yet quiet pan and tilt mechanism. This PTZ camera is ideal for

large meeting spaces, classrooms, training rooms, and many other environments. The HDVS-

CAM-HDBT is available in black or white.

1 x AT-HDVS-CAM-HDBT-BK or

AT-HDVS-CAM-HDBT-WH

1 x Wall mounting plate

1 x 1/4 20OUNC screws

1 x IR Remote Control

1 x USB A cable

1 x VISCA to RS-232 DB-9 adapter

2 x AAA battery

1 x Installation Guide

Package Contents

Installation Guide

AT-HDVS-CAM-HDBT-BK and AT-HDVS-CAM-HDBT-WH

1 RS-232

Connect included VISCA to RS-232

adapter here to control the camera with a

third party software or hardware controller.

2 AUDIO IN

Port not used.

3 HDBaseT OUT

Connect to a compatible PoE switcher

or receiver, such as: AT-OME-RX11, AT-

OME-PS62, etc.

4 LAN

Connect to a network switch to control

the unit via TCP/IP or webGUI.

5 DC 12V

Connect the included 12V power supply

to this port.

Panel Descriptions

RS-232 AUDIO

LANHDBa seT OUT

DC 12V

AT- HDVS-C AM-H DBT -BK

21 3 54

Mounting Instructions

The HDVS-CAM-HDBT has two installation options, wall mount (included) and ceiling mount

(purchased separately).

Wall Mount installation

To install the HDVS-CAM-HDBT, 4 M6 swelling bolts, 1 1/4 20UNC bolt, 4 M6 nuts & shims, the

included wall mount bracket, and the HDVS-CAM-HDBT are needed.

1 Install the M6 swelling bolts in a rectangular pattern on the wall, 100 mm wide and 50 mm

high.

2 Attached the wall mount bracket onto the wall, by placing them on the M6 swelling bolts

and securing it with the M6 nuts and shims.

3 Once the wall mount bracket is secure on the wall, place the camera on the top of the wall

mount bracket and secure it with the 1/4 20UNC bolt.

Installation Guide

AT-HDVS-CAM-HDBT-BK and AT-HDVS-CAM-HDBT-WH

Ceiling Mount installation

To install the HDVS-CAM-HDBT, 4 PA3X30 self-tapping screws, 4 PM3X6 screws, 4 screw

stoppers, 1 1/4 20UNC screw, the optional ceiling upper and lower covering plates, and the

HDVS-CAM-HDBT are needed.

1 Install the 4 screw stoppers in the ceiling.

2 Connect the upper ceiling covering plate to the screw stoppers using the PA3X30 self-

tapping screws.

3 Connect the lower ceiling covering plate to the bottom of the HDVS-CAM-HDBT using the

1/4 20UNC screw.

4 Mount the lower ceiling covering plate to the upper ceiling plate using 3 PM3X6 bolts.

ON KE

1 2

ON KE

1 2

NOTE: The camera picture will need to be

inverted for video to be viewed correctly. View

the HDVS-CAM-HDBT manual for instructions on

how to invert video.

Product specificaties

Merk:	Atlona
Categorie:	Video conferentie systeem
Model:	AT-HDVS-CAM-HDBT
Kleur van het product:	Zwart
Gewicht:	1400 g
Breedte:	150 mm
Diepte:	150 mm
Hoogte:	167.5 mm
Stroom:	1 A
Ondersteunde video-modi:	720p, 1080i, 1080p
Type stroombron:	AC
Minimale belichting:	0.5 Lux
Maximale beeldsnelheid:	60 fps
Inclusief AC-adapter:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	2
Diafragma (F-F):	1.3 - 3
Brandpuntbereik:	4.7 - 47 mm
DC voltage input:	12 V
Certificering:	CE, FCC
Omvang optische sensor:	1/2.8 "
Aansluiting voor netstroomadapter:	Ja
Megapixels:	2.07 MP
Type beeldsensor:	CMOS
Optische zoom:	10 x
Maximale videoresolutie:	1920 x 1080 Pixels
HD type:	Full HD
RS-232 port:	1
Temperatuur bij opslag:	-10 - 60 °C
Luchtvochtigheid bij opslag:	20 - 95 procent
Signaal/ruis-verhouding:	55 dB
Scherpstellen:	Automatisch/handmatig
PTZ control:	Ja
Ondersteunde protocollen:	VISCA, Pelco-D, Pelco-P
Pan bereik:	-170 - 170 °
Stroomverbruik (typisch):	12 W
Bedrijfstemperatuur (T-T):	-10 - 50 °C
Relatieve vochtigheid in bedrijf (V-V):	20 - 80 procent
Bereik kantelhoek:	-30 - 90 °
Code geharmoniseerd systeem (HS):	85258900
Groothoekstand kijkhoek (normale modus):	60.9 °
Telestand kijkhoek (normale modus):	6.43 °
Tiltsnelheid (max):	80 °/sec
Pansnelheid (max):	180 °/sec
Tiltsnelheid (min):	0.1 °/sec
Pansnelheid (min):	0.1 °/sec
Vermogensverdeler afmetingen (BxDxH):	50 x 94 x 32.05 mm
