INSTALLATION INSTRUCTIONS
HPG-370GA
SIREN LOUDSPEAKER
TheModelHPG-370GSirenLoudspeakerisutilizedforhighpoweredtransmissionofelectronicsirenan A d
voicecommunicationsinvehicularapplications.Itissuitableforinstallationwithinlightbars,enginecompart -
mentsorformountinginfrontoftheradiatororonthebumperofanyambulance,fire,lawenforcement,utilit y
orotherpublicservicevehicle.Itisratedat100wattsRMSinelectronicsirenuseandwillprovide a dsoun
leveloutputof 116dB(measuredat1600Hz,ratedpowe r, 3 a ,metersonaxis).Itisfurnishedwithonepiece
steelmountingbracketandhas a y.Field terminations are via 20"field-replaceabledriver-headassembl
(508mm) 18-guage, color-coded wire leads. Lead color is and . The lead is connected toREDBLACKRED
the #2 positive driver terminal. y, d(ReplacementheadassemblModelK-370A,isavaiableforfeil
replacementofModelSD-370A) .
MODELPOWER RATINGIMPEDANCEFREQ.RESPONSEDISPERSION
HPG-370GA100 Watts11 Ohms450 - 3500 Hz80˚ x 105˚
RMSNominal±10dB Nominal1KHz Octave Band
7
15
⁄16"
5
3
⁄8"
1"
7"
.266 x .562 OBR.
2-PLCS.
.266 x 1.000 OBR.
4-PLCS.
2.50
.28
.38
4.19
4.00
4.75
HOLD
2.38
.187 x .687 OBR.
2-PLCS.
.59
.91
2.62
3.47
Driver Side
Note:The weep hole located in the front of the driver must be postioned at 6:00 o’clock when installed.
