RT-BE58 Go

BE3600 Dual Band WiFi Router

Quick

Start Guide

Hardware Explanations

I/O Ports Overview

LED Lights Overview

DC Power input

USB-C PD Type:

+12V/2A, +9V/2A

Operating Temperature0~40

o

CStorage0~70

o

C

Operating Humidity50~90%Storage20~90%

Specications:

Prepare your Modem

01

1

Unplug the power of cable / DSL modem. If it has a

battery backup, remove the battery.

1

5

[App] Launch ASUS Router app and follow the

instructions to complete the setup.

Modem back

Unplug

Install your Router

02

1

Plug the adapter into the DCIN port.

2

Connect your modem to WAN port at the back side of the router with the

network cable provided.

3

Power on the modem. Plug modem to the power outlet and power on.

Modem back

4

Check the modem LED lights to ensure the connection is active.

1

If you are using DSL for internet, you

will need your username / password

from your Internet service provider

(ISP) to properly congure your

router.

Modem front

– Or via web browser

3

[Wired] Connect your PC to LAN port at the back side of the

router using an additional network cable.

[Wireless] Connect to the network with default SSID shown on the product

label on the bottom side of your router “ASUS_XX”.

4

[Wired / Wireless] Open a web browser.

You will be redirected to the ASUS Setup Wizard. If not, navigate to

http://www.asusrouter.com.

Follow the instructions to complete the setup.

http://www.asusrouter.com

Welcome

Quick Internet Setup

START

– Via app

3

[App] On your iOS or Android mobile device, go to the app store,

search forASUS Router, and download the app.

4

[App]On your iOS or Android mobile device, tapSettings > Wi-Fi, connect

to the default network SSID shown on the product label on the bottom of

the router. Or scan the code on the product label to connect the default

network SSID.

* XX refers to the last two

digits of MAC address.

You can nd it on the

label on the bottom side

of your router.

Create a New Network

Advanced Settings

Welcome to RT-BE58 Go

LED

2

The LED will light up when the hardware is ready.

USB Type-C (DCIN) port

1 GbE LAN port

2.5 GbE WAN port

Reset button

USB 3.0 Gen1x1 port

E26687

Router Setup Steps

ASUS Router

Slide switch

LED indications

Breathing green: Your RT-BE58 Go is starting up

Solid blue (Standby): Your RT-BE58 Go is ready for setup

Solid white: Your RT-BE58 Go has connected to Internet

Solid red: Your RT-BE58 Go has disconnected from Internet

Breathing blue:Your RT-BE58 Go is connecting to a public

WiFi (WISP mode)

Blinking yellow:Your RT-BE58 Go is resetting to factory

defaults
