Motherboard

ROG

MAXIMUS

Z790

HERO BTF

E23156

First Edition

February 2024

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by

any means, except documentation kept by the purchaser for backup purposes, without the express

written permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless

such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM

ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN

THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identification or explanation and to the

owners’ benefit, without intent to infringe.

Product specificaties

Merk:	Asus
Categorie:	Stopcontact
Model:	ROG MAXIMUS Z790 HERO BTF
Kleur van het product:	Zwart
Breedte:	305 mm
Diepte:	244 mm
Bluetooth:	Ja
Wi-Fi-standaarden:	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Bluetooth-versie:	5.4
Ethernet LAN:	Ja
Type stroombron:	ATX
Meegeleverde kabels:	SATA
Aantal HDMI-poorten:	1
Microfoon, line-in ingang:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	1
Hoofdtelefoonuitgangen:	1
HDMI versie:	2.1
Wifi-standaard:	Wi-Fi 7 (802.11be)
Ondersteunt Windows:	Windows 10, Windows 11
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	4
Processor socket:	LGA 1700
Processorfabrikant:	Intel
Maximum intern geheugen:	192 GB
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C:	1
Audio-uitgangskanalen:	7.1 kanalen
Ethernet interface type:	2.5 Gigabit Ethernet
Lijningang:	Ja
Chipset moederbord:	Intel Z790
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A:	5
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC4082
Meegeleverde drivers:	Ja
S/PDIF-uitgang:	Ja
RAID support:	Ja
Geheugen kanaal:	Dubbelkanaals
Maximum aantal HDD's per behuizing:	4
Ondersteunde opslagstationinterfaces:	M.2, SATA III
Hoeveelheid Thunderbolt ports:	2
Component voor:	PC
Soorten RAID:	0, 1,5, 10
Aantal SATA III connectors:	4
Compatibele processors:	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium Gold
Aantal storage drives ondersteund:	9
Ondersteunde geheugen types:	DDR5-SDRAM
Wifi:	Ja
Ondersteunde types opslag-drives:	HDD & SSD
Moederbord chipset familie:	Intel
Moederbord form factor:	ATX
Aantal geheugenslots:	4
Supported memory clock speeds:	4800,5000,5200,5400,5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600,7800,8000 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	256 Mbit
Ondersteuning voor parallel processing:	Niet ondersteund
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	4
ATX Power connector (24-pin):	Ja
USB 2.0 aansluitingen:	2
Aansluiting voor audiopaneel aan voorzijde:	Ja
Niet gebufferd geheugen:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	2
EPS power connector (8-pin):	Ja
Clear CMOS knop:	Ja
WiFi-AP antenna jack:	2
Supported processor sockets:	LGA 1700
Aantal M.2 (M) slots:	5
12V vermogen-connector:	Ja
RGB LED-aansluitrail:	Ja
Ondersteunde geheugenkloksnelheid (max):	8000 MHz
Back-to-BIOS button:	Ja
PCI Express x16 (Gen 5.x) sleuven:	1
PCI Express x4 (Gen 4.x) sleuven:	1
USB 3.2 Gen 2x2-aansluitingen:	1
