QUICK START GUIDE
SVSI Mounting Wings
© 2018 Harman. All rights reserved. AMX, AV FOR AN IT WORLD, and HARMAN, and their respective logos are registered trademarks of HARMAN.
Oracle, Java and any other company or brand name referenced may be trademarks/registered trademarks of their respective companies.
AMX does not assume responsibility for errors or omissions. AMX also reserves the right to alter specifications without prior notice at any time.
The AMX Warranty and Return Policy and related documents can be viewed/downloaded at www.amx.com.
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 AMX.com | 800.222.0193 | 469.624.8000 | +1.469.624.7400 | fax 469.624.7153
AMX (UK) LTD, AMX by HARMAN - Unit C, Auster Road, Clifton Moor, York, YO30 4GD United Kingdom • +44 1904-343-100 • www.amx.com/eu/
800-0001 REV:B
Last Revised: 4/2018
Basic Installation Guidelines
The NMX-ACC-N9101 Mounting Wings are used to mount N-Series SVSI Encoders,
Decoders, and Audio Transceivers to a surface or wall. Follow these instructions for
proper installation.
1.Remove two screws from the bottom of the unit you wish to mount. The two
screws you remove should be on the same side of the unit (as shown below).
CAUTION: Do not remove all four screws at once.
2.Align and secure the first mounting wing to the bottom of the unit, using the
same t
wo screws you just removed. Make sure the screws are tightened properly.
Align and tighten screws
3.Remove the remaining two screws.
Remove screws
4.Align and secure the second mounting wing to the bottom of unit, using the same
two screws you just removed. Make sure the screws are tightened properly.
Align and tighten screws
Please contact SVSI technical support at s[email protected] or 256.461.7143
x9900 for any installation issues.
Remove screws
