Installation Guide
CP-RC01, IR Remote
For full warranty information, refer to the AMX Instruction Manual(s) associated with your Product(s).
11/10
©2010 AMX. All rights reserved. AMX and the AMX logo are registered trademarks of AMX.
AMX reserves the right to alter specifications without notice at any time.
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • fax 469.624.7153 • technical support 800.932.6993 • www.amx.com
93-1302-70REV: A
Overview
TheCP-RC01IRRemote()(FIG.1)provideslocalcontrolofFG1302-70
CP-3008andCP-3017seriesControlPads.
Product Specifications
Button Functions
YoucancreateaCP-3000scriptforeachbuttonontheremotetoperforma
specifictaskwhenpressed.ThebuttonscanbeprogrammedbyusingAMX
DCSsoftwaretoprogramavirtualbutton.EachbuttonhasacorrespondingIR
remotecode.SeethesectionforalistofIRremotecodes.IRRemoteCodes
Toprogramabuttonfunction,writeascriptforavirtualbuttonnumberedwith
thecorrespondingIRremotecodeforthebuttonontheremoteplus100.For
example,ifyouwanttoprogramthePowerbuttonontheremote,youshould
writeascriptforvirtualbutton109(9+100).Selectthevirtualbuttonfromthe
ButtonNummenuintheButtonEventareaoftheAMXDCSwindow.
FormoreinformationaboutscriptingandusingAMXDCS,consulttheNOVARA
3000-SeriesControlPadsOperation/ReferenceGuide.
IR Remote Codes
ThefollowingtableliststheIRcodesfortheCP-RC01remote.
FIG.1CP-RC01 IR Remote
CP-RC01 IR Remote
Dimensions(HWD):8”x2”x1”(20cmx5.5cmx2.8cm)
Weight:Withoutbatteries:0.208lbs(94.34g)
Battery:2AAABatteries
PowerConsumption:Approximately50mAatIRtransmit
IRTransmit
Frequency:
38KHz
Range:20-30ft(6-9m)Standard
Note:Rangecanbeaffectedbyfactorssuchasangleof
incidenceandLEDgraphbrightness.
Operating
Environment:
•Storagetemperaturerange:-40°-158°F(-40°-70°C)
•Operatingtemperaturerange:41°-104°F(5°-40°C)
•Relativehumidity:10%to90%,non-condensing
FIG.2
Button Event area of the AMX DCS window
Selecta
virtual
button
fromthis
menu.
IR Remote Codes
ButtonCodeButtonCode
Mute26Record8
Power9Pause2
PC30Stop3
STB31VolumeUp24
Disc32VolumeDown25
Aux33PageUp106
Red71PageDown107
Green72ChannelUp22
Yellow73ChannelDown23
Blue74111
Exit50212
Info101313
Up45414
Down46515
Left47616
Right48717
OK49818
Guide105919
Menu44010
Rewind5Subtitle100
Play1Prev81
FastForward4
