- 1 -
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2016
Thank you for selecting American Standard...
the benchmark of fine quality for over 100 years.
To ensure that your installation proceeds smoothly-please
read these instructions carefully before you begin.
RECOMMENDED TOOLS
M965724 Rev. 1.0 (7/16)
ROUGHING-IN DIMENSIONS
TOWNSEND
®
BATH AND SHOWER
TRIM KIT
INSTALLATION
INSTRUCTIONS
T353.500
T353.501
T353.502
T353.507
T353.508
Plumbers’ Putty
or Caulking
Adjustable WrenchChannel Locks
Phillips Screwdriver
Certied to comply with ANSI A112.18.1M
• To assure proper positioning in relation to wall.
Note roughing-in dimensions.
Teon Tape
Flat Blade Screwdriver
THREADED INLETS (STOPS)
5-7/8"
(149 mm)
5-7/8"
(149 mm)
INLETS 1/2" NPT
(13 mm)
INLETS
1/2" NPT
(13 mm)
OUTLETS
1/2" NPT
(13 mm)
OUTLETS
1/2" NPT
(13 mm)
3-3/8"
(86 mm)
3-3/8"
(86 mm)
3-3/8"
(86 mm)
THREADED INLETS
4"
(102 mm)
BOTTOM OF TUB
74" (1880 mm)
FOR HEAD
CLEARANCE
18" (457 mm)
OPTIONAL
6.5" REF.
(165 mm)
1/2" (12 mm) NPT
1/2" (13 mm)
COPPER
7-1/4"
(184 mm)
OPTIONAL TO FINISHED
FLOOR USUALLY
BETWEEN 65'' AND 80''
(1651 AND 2032 mm)
TOP OF TUB RIM
SHR. 1/2" (13 mm) NOM.
COPPER SWEAT
TUB 1/2" (13 mm) NOM.
COPPER SWEAT
SHR. 1/2" (13 mm) NOM.
COPPER SWEAT
TUB 1/2" (13 mm) NOM.
COPPER SWEAT
4-1/16"
(103 mm)
4-1/16"
(103 mm)
INLETS
4-1/16"
(103 mm)
2"
(51 mm)
SWEAT
INLETS
SWEAT
INLETS (STOPS)
INLETS
1/2" (13 mm) NOM.
COPPER SWEAT
INLETS
1/2" (13 mm) NOM.
COPPER SWEAT
1-5/8" TO 3-1/4"
(41 TO 83 mm)
1-5/8" TO 3-1/4"
(41 TO 83 mm)
FINISHED WALL
3.3/8" (85 mm) REF.
7" (177 mm) REF.
2-9/16"
(65 mm)
1-1/2" REF.
(38 mm)
