M965757 Rev. 1.0 (7/17)

Product names listed herein are trademarks of AS America, Inc.

© AS America, Inc. 2017

RECOMMENDED TOOLS AND MATERIALS

Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing

supply stores. It is essential that the tools and materials be on hand before work is begun.

CARE AND CLEANING

Do: Simply rinse the product clean with clear water, dry with a soft cotton flannel cloth.

Do Not: Clean the product with soaps, acid, polish, abrasives, harsh cleaners, or a cloth with a coarse surface.

Showerhead

For all Models

Plumbers' Grease

Adjustable WrenchTeon Tape

Channel Locks

Finished Floor Usually

Between 65" and 78"

(1651 and 1981 mm)

Finished Wall

74" (1880 mm)

for Head

Clearance

from Bottom

of Tub

Shower

Arm

Support

Bottom

of Tub

Apply Sealing Tape

to all Threaded

Connections.

Install Shower Arm,

Showerhead

Long End

ROUGH-IN

DIMENSIONS

INSTALL SUPPORTS

FOR SHOWER

Thank you for selecting American Standard...

the benchmark of fine quality for over 100 years.

To ensure that your installation proceeds smoothly-please read

these instructions carefully before you begin.

INSTALLATION

INSTRUCTIONS

Certied to comply with ANSI A112.18.1M
