RECOMMENDED TOOLS
Flat Blade Screwdriver
Adjustable Wrench
Slip Jaw Pliers
Plumbers' Putty or Caulking
Phillips Screwdriver
Teflon Tape
Thank you for selecting American-Standard...the benchmark of fine
quality for over 100 years.
To ensure that your installation proceeds smoothly-- please read these
instructions carefully before you begin.
Certified to comply with ANSI A112.18.1
ROUGHING-IN DIMENSIONS (For reference only)
To assure proper positioning in relation to wall, note roughing-in dimensions.
PRESSURE BALANCING
BATH AND SHOWER
TRIM KITS
M965625 REV. 1.1 (11/14)
FLUENT™
Installation
Instructions
T186.500
T186.501
T186.502
T186.507
T186.508
FINISHED
WALL
TOP OF TUB RIM
BOTTOM OF TUB
5" REF.
(127mm)
3-3/4" REF.
(95mm)
1/2" COPPER
7-1/2" REF.
(191mm)
8-1/2" REF.
(216mm)
"SEE ILLUSTRATION "
THREADED INLETS (STOPS)
THREADED INLETS
THREADED INLETS (STOPS)
INLETS
1/2" NPT
(13mm)
5-7/8"
(149mm)
INLETS 1/2" NPT (13mm}
OUTLETS
1/2" NPT
(13mm)
OUTLETS
1/2" NPT
(13mm)
3-3/8"
(86mm)
3-3/8"
(86mm)
3-3/8"
(86mm)
4" (102mm)
74" FOR HEAD
CLEARANCE
(1880mm)
18" OPTIONAL
(457mm)
OPTIONAL TO FINISHED
FLOOR USUALLY
BETWEEN 65'' AND 80''
(1651 and 2032mm)'
SHR. 1/2" NOM.(13mm)
COPPER SWEAT
TUB 1/2" NOM. (13mm)
COPPER SWEAT
4-1/16"
(103mm)
5-7/8"
(149mm)
INLETS
4-1/16"
(103mm)
4-1/16"
(103mm)
INLETS
1/2" NOM.
(13mm)
COPPER
SWEAT
SHR. 1/2" NOM.
(13mm)
COPPER SWEAT
TUB 1/2"
(13mm) NOM.
COPPER SWEAT
2"
SWEAT
INLETS
SWEAT
INLETS (STOPS)
INLETS
1/2" NOM.
(13mm)
COPPER
SWEAT
1/2" NPT
(13mm)
8" DIA.
(204mm)
6-19/32" REF.
(167mm)
1-7/8" to 3-1/4"
(48 to 83 mm)
2-7/32" D.
(57mm)
1-3/4
"
(44 mm)
O f f
C
H
507/508
500/501/502
O f f
C
H
