User Instructions
American DJ
4295 Charter Street
Los Angeles Ca. 90058
www.americandj.com
© ® - American DJ www.americandj.com - Energy One™ Instruction Manual Page 2
Unpacking: Thank you for purchasing the Energy One™ by Ameri-
can DJ . Every Energy One™ has been thoroughly tested and has ®
been shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your unit for damage
and be sure all accessories necessary to operate the unit have arrived
intact. In the event damage has been found or parts are missing, please
contact our toll free customer support number for further instructions.
Please do not return this unit to your dealer without first contacting
customer support at the number listed below.
Introduction: To optimize the performance of this product, please
read these operating instructions carefully to familiarize yourself with
the basic operations of this unit. The Energy One™ is a 200 watt
strobe, and is light weight and compact. Up to 16 units may be linked
together and controlled by single controller. A manual dimmer is built
in to the unit, allowing the unit’s intensity to be customized. The unit
also has an adjustable flash rate knob built on to the unit.
Customer Support: American DJ provides a toll free customer ®
support line, to answer any questions should you encounter problems
during your set up or initial operation. You may also visit us on the web
at www.americandj.com for any comments or suggestions. For service
related issue please contact American DJ . Service Hours are Monday ®
through Friday 9:00 a.m. to 5:00 p.m. Pacific Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2610
E-mail: support@americandj.com
Warning! To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures
warranty.
Please do not discard the shipping carton in the trash. Please recycle
when ever possible.
Energy One™ Introduction
7/03
© ® - American DJ www.americandj.com - Energy One™ Instruction Manual Page 4
Energy One™ Safety Warnings
Energy One™ Warranty Registration
© ® - American DJ www.americandj.com - Energy One™ Instruction Manual Page 3
Safety Issues: This unit may blow a fuse if the maximum allotted
load of 15 amps (7 amps 220v version) is reached. If the fuse needs
replacement, always replace the fuse with same exact type that was
remove, unless otherwise instructed by an authorized American DJ ®
service technician. Use of a different type fuse from that which is rec-
ommended may cause fire or electric shock and will void the manufac-
tures warranty.
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture.
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to remove or break off the ground prong from the
electrical cord. This prong is used to reduce the risk of electrical
shock and re in case of an internal short. Do not attempt to oper-
ate this unit if the power cord has been frayed or broken.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out-
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power cords should be routed so they are not likely to be walked
on, pinched by items placed upon or against them.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer. See page 4 for cleaning details.
• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances
(including amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the unit.
C. The unit has been exposed to rain or water.
D. The unit does not appear to operate normally or exhibits a
marked change in performance.
The Energy One™ carries a one year (365 days) limited warranty.
Please fill out the enclosed warranty card to validate your purchase.
All returned service items whether under warranty or not, must be
freight pre-paid and accompany a return authorization (R.A.) number.
The R.A. number must be clearly written on the outside of the return
package. A brief description of the problem as well as the R.A. num-
ber must also be written down on a piece of paper and included in
the shipping container. If the unit is under warranty, you must provide
a copy of your proof of purchase invoice. You may obtain a R.A. num-
ber by contacting customer support at (800) 322-6337.
Energy One™ Cleaning Instructions
Due to fog residue, smoke, and dust cleaning the fixture should be
carried out periodically to optimize light output.
1. Use normal glass cleaner and a soft cloth to wipe down the out-
side casing every 20 days.
2. Use normal glass cleaner with a soft cloth to wipe down the inside
reflector and lens every 30-60 days.
3. Always be sure to dry all parts completely before plugging the
unit back in.
4. Frequent cleaning the unit will extend lamp life and ensure the fix-
tures reliability.
Cleaning frequency depends on the environment in which the fixture
operates (I.e. smoke, fog residue, dust, dew). In heavy use we rec-
ommend cleaning on a monthly basis. Periodic cleaning will ensure
longevity, and crisp light output.
Energy One™ Features
• Bright 200 Watt Strobe Lamp
• Manual Dimmer Setting
• Adjustable Flash Rate
• Large coverage area
• Link Up To 16 Units Together
• Built-In Adjustable Hanging Yoke
• Optional Remote Control (Not Included)
Duty Cycle:
Because the Energy One™ can be used for continuous output (ie
while simulating lightning), it can build up intense heat. Due to this
intense heat built up the unit should not run for 15 minutes continu-
ously. After 15 minutes of continuously use allow the unit to cool for
about fifteen minutes, this will greatly increase the lamp life and
insure product longevity.
Stand Alone:
In stand alone the unit will function as a normal strobe light. Rate
(speed) and Intensity (brightness) are set directly on the unit. Note
that these settings are made using the adjustable knobs on the
rear panel of the unit. Once the settings are made they can only be
changed by physically adjusting the knobs on the unit. Be aware of
this if you plan on installing your strobe in a permanent application,
if your are not satisfied with your settings you will have to physically
remove them and adjust the knobs. Experiment with the different set-
tings to achieve your desired flash.
Linking:
The units can be linked together to form a chase pattern or have
them flash simultaneously. You must have a controller connected to
the rst unit in the chain. If you don’t have a controller connected,
the units will not interact.
Optional Remote:
American DJ offers several remote controls that may be used to ®
control the unit by remote such as the S-10S controller. Some remote
controls will allow you to chase several strobes and some may allow
you to only adjust the flash rate. The remote operations very by
model, please see your dealer or visit our web site for more informa-
tion on the available remote controls.
© ® - American DJ www.americandj.com - Energy One™ Instruction Manual Page 5
Energy One™ Operating Instructions
Energy One™ Lamp Replacement
Caution: Always replace with the exact same type lamp and fuse,
unless otherwise specified by an authorized American DJ techni-®
cian. Replace with anything other than the specified part can damage
your unit and will void your manufactures warranty.
Warning: If after you have replaced the lamp or fuse and you con-
tinue to blow either one, STOP using the unit. Contact customer sup-
port for further instructions, you may have to return the unit for ser-
vicing. Continuing to use the unit may cause serious damage.
Lamp Replacement: Caution! Never open the unit when in use.
Always disconnect the main power and allow the fixture ample time
to cool before attempting to replace the lamp. Again, please remem-
ber to always replace with the exact same type lamp.
1. Be sure to follow the proper procedures when handling strobe
lamps. Never touch the new lamp with your bare fingers.
2. Unscrew the six phillips screws that run along the bottom sides of
of the unit (three on each side).
3. Seperate the base and the cover.
4. Unscrew and disconnect the three wires from the PCB.
Remember which wire went where.
5. Push the lamp holders out to remove the lamp.
6. Remove and replace the lamp with an exact match. Remove the
silicon wire covers from the old lamp, and use them to cover the
new lamp wires’.
7. Connect the three wires to the correct points on the PCB.
8. Reassemble in reverse order.
For illustrated instructions on how to replace the lamp, see the
next page.
Strobe Lamp Warning! This fixture is fitted with a
strobe lamp which are highly susceptible to dam-
age if improperly handled. Never touch the lamps
with your bare fingers as the oil from your hands will
shorten lamp life. Also, never move the fixture until
the lamps have had ample time to cool. Remember,
lamps are not covered under warranty conditions.
© ® - American DJ www.americandj.com - Energy One™ Instruction Manual Page 6
Locate and remove the unit’s power cord. Once the cord has been
removed locate the fuse holder inside the power socket. Insert a flat-
head screwdriver into the power socket and gently pry out the fuse
holder. Remove the bad fuse and replace with a new one. The fuse
holder has a built-in socket for a spare fuse be sure not to confuse the
spare fuse with active fuse.
Energy One™ Fuse Replacement
Product specificaties
| Merk: | American Audio |
| Categorie: | Niet gecategoriseerd |
| Model: | Energy One |
Heb je hulp nodig?
Als je hulp nodig hebt met American Audio Energy One stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Niet gecategoriseerd American Audio
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
Handleiding Niet gecategoriseerd
- Hapro
- Shokz
- Doro
- Aeris
- Lyman
- Carcomm
- Cotek
- Zomo
- Rittal
- AirExchange
- MEE Audio
- Prologue
- Atlantis Land
- Dragonshock
- Strex
Nieuwste handleidingen voor Niet gecategoriseerd
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
15 Augustus 2025
