Imported & Sold

excluSIvely By

Importadoy

vendIdo de Forma

excluSIva por

aldI

Batavia,

iL 60510

User ManUal

Manualdelusuario

Made in China · heCho en China

1

YEAR WARRANTY

aÑO DE GaRaNtÍa

aftER SaLES SuppORt • SERviciO pOSvENta 860085

US

1855 7548 297

SERvicE-uS@pROtEL-SERvicE.cOm

mODEL/mODELO: tBf-1 06/2026

ORiGiNaL iNStRuctiON maNuaL · maNuaL DEL uSuaRiO ORiGiNaL

V01⁄0025

TableTop bladeless Fan

5 product overvIew



Main unit



Air inlet grille



Air outlet



Base



RGB Ambient Light Ring



USB-C Charging Port



Display and control panel



USB-C Charging Cable

















4.2 ExpLaNatiONOf SymBOLS

The following symbols are used in this manual, on the product, or on the packaging.

Read the manual carefully before you use the product.

Products marked with this symbol are operated with direct current (DC).

Use the product only in dry indoor environments.

This symbol provides you with useful additional information for assembly or operation.

4.3 GENERaL SafEty iNStRuctiONS

WARNING! RISK OF ELECTRIC SHOCK!

»Faulty electrical installation or excessive mains voltage can lead to electric shock.

• The product must never be immersed in water or any other liquids, nor should it come into contact with them.

• Avoid using the device in the vicinity of moisture sources, such as baths, showers, or outdoors.

• This product is not suitable for use in high humidity environments, including bathrooms, saunas, etc., nor is it designed for outdoor use.

• Ensure the electrical outlet is easily accessible for quick disconnection of the power plug when necessary.

• Never handle the product with wet hands.

• Any modifications to the device are strictly prohibited. Repairs should only be conducted by a certified technician. Refer to the warranty

conditions provided.

• The product should not be used in the vicinity of bathtubs, showers, swimming pools, or any vessels filled with water.

• Do not operate this product in the presence of flammable or explosive gases.

• Dispose of the fan in accordance with the instructions shown in the chapter DISPOSE OF THE PRODUCT.

• This product shall be recharged only with the specified charger or DC 5V USB power source.

• Use this battery operated fan only with the battery pack specified. Use of any other batteries may create a risk of fire.

• When battery pack is not in use, keep it away from other metal objects such as paper clips, coins, keys, nails, screws, or other small metal

objects that can make a connection from one terminal to another. Shorting the battery terminals together may cause sparks, burns, or a fire.

• Do not incinerate this fan, even if it is severely damaged. The batteries can explode in a fire.

WARNING!

»Hazards for children and persons with reduced physical, sensory, or mental abilities (for example, partially disabled individuals, elderly

people with limitations in their physical and mental abilities) or lack of experience and knowledge (for example, older children).

• The product is suitable for use by children aged 8 years and older and by individuals with reduced physical, sensory, or mental capabilities, or

with limited experience and knowledge, only if they are under supervision or have been given instruction concerning safe use of the appliance

and understand the associated risks.

• Children must not play with the appliance. Supervision is required when the appliance is used near children, and maintenance tasks should

not be performed by children unless they are supervised.

• Keep all packaging materials out of reach of children to avoid suffocation risks. Never allow children to place bags or wrap on their heads.

6 dISplay and control panel operatIon



LED display



RGB light button



Power button



Timer button



Swing button

7 BeFore FIrSt uSe

7.1 chEck pRODuct aND cONtENtS

WARNING! RISK OF SUFFOCATION!

»Keep all packaging materials away from children and pets – these materials pose potential hazards, such as choking or swallowing small

parts.

CAUTION! RISK OF DAMAGE!

»Be careful when opening the packaging to avoid damaging the product. Do not use sharp objects.

1. Remove the product from the packaging.

2. Remove all packaging materials and any plastic or protective films.

3. Check that all items are included (see chapter pRODuct OvERviEw).

4. Inspect the product and its components for damage. If you notice any damage, do not use the product. Instead, contact the service center

using the contact information provided on the cover page of this manual.

5. When selecting a location ensure there is a minimum distance of 1.5 meters between the product and any surrounding objects.

6. Position the product so that its airflow does not directly impact people, pets, or plants when initially activated.

7. Fully charge the product before first use.









WARNING! RISK OF INJURY!

»Improper handling of the product can lead to injuries.

• Do not insert fingers, objects, or any part of the body into the product‘s grille or openings at any time.

• Position the cable so it is not stretched across walkways, where it could become a trip hazard.

DANGER! RISK OF BATTERY LEAKAGE, EXPLOSION, FIRE, OR POISONING!

»Improper battery handling may cause leakage, explosion, or fire, leading to burns or toxic exposure.

• Keep batteries out of reach of children. In case of accidental injury, seek immediate medical attention.

• Do not short-circuit, disassemble, or attempt to open the battery. This may cause overheating, fire, or explosion.

• This product contains a built-in rechargeable battery, which is not replaceable. When the battery reaches the end of its life, dispose of the

entire product properly in accordance with local regulations.

• Avoid applying mechanical stress to the battery.

• Keep the product away from extreme temperatures and direct sunlight, such as near radiators or other heat sources.

• Never expose the battery to fire or water.

• Stop using the product if the battery shows signs of leakage, swelling, or damage.

• Leaking or damaged batteries can cause chemical burns. Use protective gloves when handling and avoid contact with skin, eyes, or mucous

membranes.

• If battery acid contacts the skin or eyes, rinse immediately with plenty of clean water and seek medical attention.

• Do not exceed the recommended charging time. Overcharging can lead to overheating and reduce battery lifespan.

• Do not charge the product via the magnetic connection or through any magnetic power bank. Always charge only through the USB-C charging

port.

CAUTION! RISK OF DAMAGE!

»Improper handling of the product can lead to damage to the device.

• Refrain from touching any parts while they are in motion.

• Place the product away from intense heat sources like heaters or stoves.

• Ensure free airflow around the product; avoid using it in dusty areas and do not cover the vents.

• The product has feet that could be affected by some floor treatment substances. If in doubt, use a non-slip mat underneath.

• Keep the product away from TVs or radios to prevent possible interference with signal reception.

• The oscillation function is motor-driven; do not manually force the product to turn.

• For cleaning, avoid harsh chemicals, abrasive materials, and excessive water. Use a soft, damp cloth instead.

• Do not clean the unit by spraying it or immersing it in water.

• Under the environment with electrostatic discharge (ESD), the product may malfunction and need user reset to recover.

8 operatIon

8.1 chaRGiNG thE pRODuct

• Connect the USB-C charging cable  to the USB-C charging port .

• Connect the other end to a suitable power source.

Charging indication:

• The LED display  shows “--” and flashes while charging, indicating that the product has been connected to the power supply and has

entered standby mode.

• When fully charged, “--” remains illuminated continuously.

Charging time: approx. 5 hours

8.1 SwitchiNG thE pRODuct ON / Off

• Press and hold the Power button  for approx. 3 seconds.

• The product switches ON and starts at speed level 1.

The LED display  shows F1.

• To switch the product OFF, press and hold the Power button  for approx. 3 seconds.

The LED display  shows “--”.

8.2 aDjuStiNG thE faN SpEED

• When the product is switched ON, tap the Power button  lightly to cycle through the speed levels: F1 → F2 → F3

• After F3, tap the Power button  once more to switch the speed back to F1.

F1 (Speed level 1) → F2 (Speed level 2) → F3 (Speed level 3) → F1 (Speed level 1)

8.3 uSiNG thE SwiNG fuNctiON

• When the product is ON, tap the Swing button  to activate oscillation.

• The swing angle changes with each tap:

• 30° → Display shows 3

• 60° → Display shows 6

• 90° → Display shows 9

• 120° → Display shows 12

• Tap the Swing button  again to stop the swing function

WARNING! RISK OF DAMAGE!

»Improper handling of the product can lead to damage to the device.

• The oscillation function (Swing) is controlled by an internal motor. Do not attempt to manually turn the product head by hand.

8.4 uSiNG thE RGB amBiENt LiGht

• Tap the RGB light button  to switch the ambient light ON.

• Each tap changes the color (7 colors in total).

• After the 8th tap, the RGB light switches OFF.

Automatic RGB mode:

• Press and hold the RGB light button  for approx. 3 seconds.

1 Scope oF delIvery

Check the delivery for completeness and notify us within 14 days of purchase if the delivery is not complete. The package you purchased should

contain the following:

1. TBF-1 Tabletop Bladeless Fan

2. USB-C Charging cable (180 cm)

3. User manual

2 General InFormatIon

This user manual (hereinafter referred to as the “manual”) is part of the product and contains important information regarding

startup and usage.

Please read the manual carefully especially the safety section before using the product. Failure to follow the instructions in this

manual may result in serious injury and/or damage to the product.

Keep this manual for future reference. If you pass the product on to a third party, make sure to include this manual. If you need a digital copy of the

manual, please contact the service center.

3 Intended uSe

The product is intended for the ventilation of enclosed, dry indoor spaces. It is designed solely for personal, non-commercial use.

Operate the product strictly as outlined in this instruction manual. Any alternative application is deemed to be outside of the designated use and

may cause damage to property or personal injury. The product is not intended for use by children as a plaything.

Neither the manufacturer nor the distributor accepts any liability for damage or injury resulting from improper or incorrect use.

4 SaFety

4.1 ExpLaNatiONOf SiGNaL wORDS

The following signal words are used in this manual, on the product, and/or on the packaging.

DANGER!

»This signal word indicates a hazardous situation which, if not avoided, will result in death or serious injury.

WARNING!

»This signal word indicates a hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION!

»This signal word indicates a hazardous situation which, if not avoided, may result in minor or moderate injury.

CAUTION!

»This signal word also indicates a hazardous situation which, if not avoided, may result in property damage.

NOTICE

»This signal word is used to highlight helpful tips and best practices that are not related to personal injury.
