Pagina 1/2

owners. Tested to Comply with FCC and CE Standards. HOME OR OFFICE USE.

www.alogic.co

USB-C

Ultra Portable Dock PLUS

- with 4K & 100W Power Delivery

Docking Station

USB-C

4K Video

USB 3.1 (Gen 1) Hub

Eliminates

Interferences

Gigabit Ethernet

Flexible Cable

Aluminium

Construction

SD & Micro SD

100W Power Delivery

Dual Display*

Truly Universal: Connect all you want

The dock PLUS features a full array of ports

ranging from 1 x HDMI with support for 4K@30Hz,

1 x Mini DisplayPort with support for 4k@30Hz, 1

x Gigabit Ethernet for wired ethernet, 2 x USB 3.1

(USB-A) ports for your standard USB accessories,

1 x Micro SD and SD Card Readers and 1 x USB-C

port with support for up to 100W of Power Delivery

for charging your laptop when connected to a

suitable USB-C Charger.

* Dual Display Window Only

Part no.

ULDPLS-SGR ULDPLS-SLV

Compatibility

owners. Tested to Comply with FCC and CE Standards. HOME OR OFFICE USE.

www.alogic.co

Package Includes Warranty

User Interface

Input

Output

Ethernet

Physical Characteristics

Dimensions(mm)

Weight

136.1(L) X 52(W) X 15(H) mm

138gms

Resolution

Single Monitor (HDMI)

Single Monitor (Mini

DisplayPort)

Dual Monitor (HDMI +

Mini DisplayPort) *

4K@30Hz

1920x1080

* Dual monitors only compatible with Windows 10 and above computers

USB-C Dock PLUS x 1

User’s Manual x 1

Data Rate

Supports USB 3.1 Gen 1 Data Rate from USB-C and USB-A Ports

System Requirement

USB-C Ports with DP alt Mode or Thunderbolt 3 Ports

Windows 10 & above, Chromebook and Mac OS & above

Power

Supports up to 100W Power Delivery via USB-C Port

2 Year

1 x USB-C

1 x HDMI, 1 x Mini Displayport,

2 x USB 3.1 (Gen 1) Type A,

1 x USB-C Port (Power Delivery + Data),

1 x Gigabit Ethernet, 1 x SD Card Slot,

1 x Micro SD Card Slot

10/100/1000 BASE-T

Single 4K or Dual 1080p Monitors

The Dock PLUS supports either a single monitor

with up to 4K resolution when one of the HDMI

or It can also support two monitors with up to

1080p FULL HD resolution simultaneously when

the HDMI and Mini DisplayPort outputs are used

together.

The Dual monitor support is only compatible with Windows 10 and

above computers. Only single monitor is supported on Mac computers.

Power Delivery 3.0 Technology:

Data + Power

The Docking station uses the latest Power

Delivery (PD 3.0) speciﬁcation, that lets

you charge your MacBook or other USB-C

enabled laptop with up to 100W of power.

Product specificaties

Merk:	Alogic
Categorie:	Cradle/docking station
Model:	ULDPLS-SLV
Kleur van het product:	Zilver
Breedte:	52 mm
Diepte:	136.1 mm
Hoogte:	15 mm
Gebruikershandleiding:	Ja
Materiaal behuizing:	Aluminium
Connectiviteitstechnologie:	Bedraad
Ethernet LAN:	Ja
Geïntegreerde geheugenkaartlezer:	Ja
Compatibele geheugenkaarten:	MicroSD (TransFlash), SD
Aantal HDMI-poorten:	1
Microfoon, line-in ingang:	Nee
Aantal Ethernet LAN (RJ-45)-poorten:	1
Netvoeding:	100 W
Resolutie (maximum digitaal):	3840 x 2160 Pixels
Aantal per verpakking:	1 stuk(s)
Ethernet LAN, data-overdrachtsnelheden:	10,100,1000 Mbit/s
Ondersteunt Windows:	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	2
Ondersteunt Mac-besturingssysteem:	Ja
Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C:	1
Hostinterface:	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Mini DisplayPort kwantiteit:	1
Koperen ethernetbekabelingstechnologie:	10BASE-T, 100BASE-T, 1000BASE-T
Code geharmoniseerd systeem (HS):	84733020
