Pagina 1/2

Note

• Do not deliberately damage this product and put it in damp, direct sunlight or high

temperature environment.

• If improper use, demolition or operation not according to the instructions result in any

damage of your device or product, our company will not be liable for any compensation

or maintenance responsibility.

Introduction Physical Layout

Making the Connection

FCC Warning

Features

Package Contents

Increase the functionality of your iPad Pro/Macbook Pro/Air or any other USB-C enabled device

with the ALOGIC USB-C Dock Nano Mini with USB-A. USB-C Dock Nano Mini provides you full

access to some of the most popular peripheral ports for the home, oce or on-the-go. Featuring

4K HDMI (30Hz) output for a crisp resolution when you connect to an external display monitor,

USB-A with USB 3.0 supporting up to 5Gbps data transfer rate, USB-C with Power Delivery (60W)

with audio and a 3.5mm AUX port. With a plug-and-play design, the Dock Nano Mini becomes an

extension of your device without the need for software or drivers.

1. Plug the Dock Nano Mini’s USB-C connector into your iPad Pro’s or Laptop’s USB-C port.

With a Plug and Play design, the device should work automatically without the need for

additional driver or software installation.

2. Connect your existing HDMI cable to the dock’s 4K HDMI (30Hz) output and to an

external display monitor for high-resolution presentations, video streaming and

conference calls while on-the-go. Requires direct HDMI to HDMI connection.

3. The USB-C Power Delivery (60W) port and USB-A (USB 3.0) supports rapid data transfer

to and from your device.

4. Attach your headphones to the Dock Nano Mini’s additional 3.5mm audio headphone

jack to listen to music while charging your device simultaneously for an uncompromising

portable experience.

This device complies with part 18 of the FCC Rules. Operation is subject to the following

two conditions:

NOTE: Any changes or modications to this unit not expressly approved by the party

responsible for compliance could void the user’s authority to operate the equipment

(1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause

undesired operation.

3.5mm Audio Port

USB-C Port

(Audio + Power Delivery)

4K HDMI Port

USB-A

USB-C Connector

• Highly portable due to its compact and lightweight design

• Crafted from aluminium and soft-touch ABS for an elegant design

• Includes a full array of ports – 4K HDMI (30Hz), USB-C with Power Delivery (60W) and

audio, 3.5mm audio headphone jack and USB-A (USB 3.0)

• LED light to indicate connectivity

• Universal compatibility with most USB-C devices such as the iPad Pro, Macbook Air/Pro, etc

• USB-C Dock Nano Mini with USB-A

• User Manual

Specications

Model

ULDNAMN-UA-SGR

ULDNAMN-UA-SLV

Input USB-C x 1

Output

1 x 4K HDMI (60Hz) , 1 x USB-A (USB 3.0) with 5Gbps data transfer

rate, 1 x 3.5mm Headphone jack, 1 x USB-C with Power Delivery

(30W) and Audio

Resolution 4K@30Hz

System Requirement iPad Pro, MacBook Pro/Air or any USB-C enabled devices

1 2

3 4 5

Product specificaties

Merk:	Alogic
Categorie:	Cradle/docking station
Model:	ULDNAMN-UA-SLV
Kleur van het product:	Zilver
Gewicht:	22 g
Breedte:	37 mm
Diepte:	76 mm
Hoogte:	10 mm
Gebruikershandleiding:	Ja
Materiaal behuizing:	Acrylonitrile butadiene styrene (ABS), Aluminium, Rubber
Connectiviteitstechnologie:	Docking
Ethernet LAN:	Nee
Geïntegreerde geheugenkaartlezer:	Nee
Aantal HDMI-poorten:	1
Microfoon, line-in ingang:	Nee
HD type:	4K Ultra HD
Resolutie (maximum digitaal):	3840 x 2160 Pixels
Aantal per verpakking:	1 stuk(s)
Merkcompatibiliteit:	Alle merken
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	1
Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C:	1
Compatibiliteit:	Chromebook, Macbook, iPad Pro
USB Power Delivery:	Ja
USB Power Delivery tot max.:	30 W
Overdrachtssnelheid:	5 Gbit/s
Code geharmoniseerd systeem (HS):	84733020
