Pagina 1/175

ALL-VPN10

VPN/Firewall WLAN-N WAN Router

User´s Manual

ALL-VPN10 VPN/Firewall WLAN-N WAN Router

Content

I. Introduction ........................................................................................................................... 5

II. Multi- WAN VPN Router Installation ....................................................................................... 7

2.1 Systematic Setting Process .............................................................................................................................. 7

2.2 Setting Flow Chart ........................................................................................................................................... 7

III. Hardware Installation ........................................................................................................... 10

3.1 LED Signal ...................................................................................................................................................... 10

3.2 VPN Router Network Connection ................................................................................................................. 12

IV. Login.................................................................................................................................... 13

V. V. Device Spec Verification, Status Display and Login Password and Time Setting ................... 15

5.1 Home Page .................................................................................................................................................... 15

5.1.1 WAN Status .......................................................................................................................................... 15

5.1.2 Physical Port Status.............................................................................................................................. 16

5.1.3 System Information ............................................................................................................................. 17

5.1.4 Firewall Status ..................................................................................................................................... 17

5.2 Change and Set Login Password and Time ................................................................................................... 19

5.2.1 Password Setting ................................................................................................................................. 19

5.2.2 Time..................................................................................................................................................... 20

VI. Network .............................................................................................................................. 22

6.1 Network Connection ..................................................................................................................................... 22

6.1.1 Host Name and Domain Name ............................................................................................................ 22

6.1.2 LAN Setting .......................................................................................................................................... 23

6.1.3 WAN Settings ....................................................................................................................................... 24

6.2 Multi- WAN Setting ....................................................................................................................................... 34

6.2.1 Load Balance Mode ............................................................................................................................. 35

6.2.2 Network Service Detection .................................................................................................................. 39

6.2.3 Protocol Binding .................................................................................................................................. 41

VII. Intranet Configuration .......................................................................................................... 51

7.1 Port Management ......................................................................................................................................... 51

7.2 IP/ DHCP ........................................................................................................................................................ 52

7.3 DHCP Status .................................................................................................................................................. 54

7.4 IP & MAC Binding .......................................................................................................................................... 56

VIII. Wireless Network ................................................................................................................ 60

8.1 Basic Configuration ........................................................................................................................................... 61

8.2 Security Setting ................................................................................................................................................. 63

8.3 Station List ........................................................................................................................................................ 71

IX. QoS (Quality of Service)........................................................................................................ 72

9.1 Bandwidth Management .............................................................................................................................. 73

9.1.1 The Maximum Bandwidth provided by ISP ......................................................................................... 74

Product specificaties

Merk:	Allnet
Categorie:	Router
Model:	ALL-VPN10
Kleur van het product:	Zwart
Gewicht:	425 g
Breedte:	130 mm
Diepte:	192 mm
Hoogte:	40 mm
LED-indicatoren:	Ja
Aan/uitschakelaar:	Ja
Frequentie van processor:	700 MHz
Processormodel:	Ralink RT6856
Ethernet LAN:	Ja
Frequentieband:	2.4 GHz
Aantal Ethernet LAN (RJ-45)-poorten:	4
Aantal USB-aansluitingen:	2
Aansluiting voor netstroomadapter:	Ja
Intern geheugen:	128 MB
Type processor:	Ja
Interfacetype Ethernet LAN:	Fast Ethernet
Ethernet LAN, data-overdrachtsnelheden:	10, 100 Mbit/s
Bekabelingstechnologie:	10/100Base-T(X)
Ondersteunde beveiligingsalgoritmen:	64-bit WEP, 128-bit WEP, WPA, WPA2
Antennas quantity:	2
3G:	Nee
4G:	Nee
Temperatuur bij opslag:	-25 - 70 °C
Mobiele netwerkverbinding:	Nee
Web-gebaseerd management:	Ja
Luchtvochtigheid bij opslag:	30 - 90 procent
Rack-montage:	Nee
xDSL-verbinding:	Nee
MAC adres filtering:	Ja
Filtratie:	Ja
Ethernet WAN:	Ja
Firewall:	Attack Logging, Access Control, URL/Keyword Filter
DoS aanval preventie:	Ja
Flash memory:	16 MB
Quality of Service (QoS):	Ja
Beheerprotocollen:	SNMP, SNMP Trap, NTP
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	30 - 90 procent
VPN eigenschappen:	IPSec VPN Tunnel, MD5/SHA1, DES/3DES/AES, PPTP VPN, VPN Backup, VPN Hub, NATT, QVM
Antenne-ontwerp:	Extern
NAT functionality:	One-to-One NAT/DMZ/Virtual Server, UPnP Support, Static Routing
Stateful Packet Inspection (SPI):	Ja
