Note: If the DSL LED does not turn solid on, please refer

to FAQ > Q2.

Connect the Hardware

Quick

Installation Guide

©2025 MERCUSYS 7100001206 REV1.0.0

Wireless VDSL/ADSL Modem Router

Congure the Modem Router

Wired: Turn o the Wi-Fi on your computer and connect your computer to the modem router’s LAN

port using an Ethernet cable.

Method 1: Via the Web Browser

Note: If the login window does not appear, please refer to FAQ > Q1.

Before You Start

You usually need an Internet service username and password given by your Internet Service Provider (ISP)

when you first signed up with them. If you are unsure, please check with your ISP.

1. Connect your device to the modem router (Wired or Wireless).

Wireless:

a. Find the default SSID (network name) and wireless

password printed on the label at the bottom of the

modem router.

b. Click the network icon of your computer or go to the

Wi-Fi settings of your smart device, and then select

the SSID to join the network.

2. Launch a web browser, and enter http://mwlogin.net in the address bar. Create a password to log in.

* Images may dier from actual products.

4

Power Adapter

Modem Router

3

2

Phone Cable

Phone Jack

Phone Cable

DSL Splitter

Phone (Optional)

PHONE

LINE

MODEM

Wait about 1 to 2 minutes, then verify that the

following LEDs are solid on before continuing.

If you don’t need the phone service,

directly connect the modem router to

the phone jack with the provided phone

cable, then follow steps 3 and 4 to

complete the hardware connection.

1

Wireless Password/PIN: XXXXXXXX

SSID:MERCUSYS_XXXX

Wireless Password/PIN: XXXXXXXX

SSID:MERCUSYS_XXXX

SSID:MERCUSYS_XXXX_5G

http://mwlogin.net

Start

Conrm Password

Create Password

LowMiddleHigh

3. A Quick Start window will pop up automatically when logging in for the rst time; otherwise, select

Quick Start from the menu. Follow the step-by-step instructions to set up an Internet connection.

Enjoy the internet!

SYS

On

Wi-Fi

On

DSL

On
