LED door Luminaires In

Wall Mount Over Bed –

120VAC 60Hz/

Page 1 of 1 R1 8061020

Part #: ALB374000L30EN xx

ALB495400L30ENxx

Limited Factory Warranty

AFX Inc. hereby warrants that this xture is free from defects in materials and workmanship when installed and used under normal operating conditions for a period of 5 years from date of

purchase. This warranty covers all component parts and extends only to replacement of defective xture or components; it does not cover failure due to improper installation, misuse,

mishandling or damage incurred in transit.

Safety Precautions

Read all safety precautions and installation instructions carefully before installing or servicing this xture. Failure to comply with these instructions could result in potentially fatal

electric shock and/or property damage.

It is recommended that a qualied electrician perform all wiring. This xture must be wired in accordance with all national and local electrical codes.

Do not handle any energized xture or attempt to energize any xture with wet hands or while standing on a wet or damp surface or in water.

This xture is designed for use in a 120VAC / 60Hz circuit. This xture is not compatible with dimming circuit.

Make sure that the power source conforms to the requirements of the xture. (See labels on the xture housing).

To reduce the risk of electrical shock, and to assure proper operation, this xture must be adequately grounded. To accomplish proper grounding, there must be a separate ground

wire (green) contact between this xture and the ground connection of your main power supply panel.

This xture is intended to be used for general indoor lighting in dry or damp locations.

Disclaimer

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been

tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules and Canadian ICES--005 (B). These limits are designed to 005 (B) / NMB

provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiver antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult with the dealer or an experienced radio/TV technician for help.

Any modications to this xture may void the warranty and interfere with the safe operation of the luminaire.

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may

cause undesired operation of the device.

Assembly Instructions

Step 1 Preparing for installation–

A. at fuse or circuit breaker box Disconnect electrical power

before installing or servicing any part of this xture.

B. Carefully remove the xture from the carton, remove

components from hardware kit.

C. Remove appropriate knockout(s) on channel assembly (1) for

power supply entry.

D. Line up cover plate (4) from parts bag and mount to jbox (not

included) with screws (5) from parts bag.

E. Position the channel assembly (1) onto the wall with the “this

side up” sticker facing the proper direction and mark all

appropriate mounting locations. Take the channel assembly (1)

down and punch a small hole in the wall at each of the locations

using a nail to see if there is a wall stud to mount the xture to.

Where there is a wall stud, use a suitable screw (2, not included)

to mount the xture. Where there is no stud to screw into, a

drywall anchor or toggle bolt (3, not included) must be used to

mount the channel assembly securely to the wall.

F. Feed the white, black, ground wires through knockout.

G. Install channel assembly (1) to wall using two screws (2, not included) to secure it.

Wiring All wiring must take place inside junction box (not included) –

Caution: Make sure power is o at fuse or circuit breaker box. Check power wires for damage or scrapes. If power supply wires are within three inches of

the LED driver, use wire suitable for at least 90°C (194°F). Most dwellings built before 1985 have supply wire rated to 60°C. Consult a qualieNote:d

electrician to ensure correct branch circuit conductor before installing.

Step 2 Wiring xture –

A. Make all wire connections to appropriate wire. Secure with wire nuts (provided).

B. Connect the green wire from the xture to the supply power source ground wire. Connect the white wire from the xture to the white (N) wire from supply

power source. Connect the black xture wire to the black (L) wire from supply power sourc e.

C. Pull on each wire lead to make sure connections are secure. Make certain no bare wires are exposed outside of wire connectors. Tuck all Do not mix wires.

connections neatly into the junction box.

Step 3 Cover Assembly and Diuser –

A. With cover and divider coming out of the divider/LED LED assembly (7) facing the correct direction (see “this side up” sticker), connect quick disconnect (6)

assembly with the leads that are coming out of the channel assembly. Do not mix uplight and downlight connector.

B. Mount the cover and divider LED assembly (7) to the main channel assembly (1) using two screws (8) to secure it.

C. Align the diuser (9) over the channel assembly (1) ush up against the wall with both end caps (10) over the diuser ends then using four screws (11) to

secure it.

Step 4 Restore power at fuse or circuit breaker box –

Step 5 Operation –

A. The far right pull switch operates the uplight and downlight by pulling on the chain once to turn on the uplight, pull twice to turn on the downlight, third pull to

turn on both uplight and downlight, and forth pull to turn both lights o. The left pull switch operates the night light by single pull to turn night light on and pull

twice to turn o.

xture shown for reference

only. Individual models

may vary.
