WISE-4250 Startup Manual 1
Thank you for purchasing this WISE-4250 series module.
This is a quick guide to help you deploy the WISE-4250
series module in your application eld. It includes power
and application wiring. If you need more instructions, please
refer to the user manual on the Advantech website.
Furthermore, Advantech IoT Academy has produced a
series of outstanding free courses, where IoT experts guide
you in rapidly acquiring product technical knowledge and
developing IoT projects. It is strongly recommended that
you view the videos prior to product use. You can nd the
courses here: https://academy.advantech.com/en/courses
Input Power Requirements
The WISE-4250 series system is designed for a standard
industrial unregulated 24 V
DC
power supply. For some ap-
plications, it can also accept +10 to +50 V
DC
power input,
200mV peak to peak power ripple. The immediate ripple
voltage should be between +10 and +50 V
DC
.
Packaging List
• 1 x WISE-4250 module with bundled antenna and termi-
nal connector
• 1 x Mounting bracket
• 1 x Startup Manual with China RoHS declaration
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
WISE-4250
Industrial Wireless Wi-Fi 2.4/5 GHz I/O and Sensing
Module
Startup Manual
SwitchDescriptionPosition
ON
(Default)
OFF
SW1
Operation
Mode
P1
Normal
Mode
Initial
Mode
P2N/AN/A
Note:After position 1 of SW1 has been changed, users
need to power on the module again to apply the
new operating mode.
Overview
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service:
http://support.advantech.com/
This Startup Manual is for the WISE-4250 Series.
Part No. 2041425011
Printed in Taiwan
Edition 2
March 2025
Switch Settings
