Pagina 1/7
PCE-5B05-04 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
PCE-5B05-04A1E
startup manual 1st. ED p/n: 200K5B0520
M4*6*0.7 round screws
(15 pcs.) p/n: 1939000410
2 years quality warranty
card p/n: 2190000902
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
1.
2.
3.
PCE-5B05-04A1E Backplane: 5-slot BP for 5-slot Chassis, 1 PICMIG
1.3, 4 32-bit PCI
Startup Manual
Standard Functions
PICMIG 1.3 slots: PCE-5B05-04 backplane supports
PCE-5xxx CPU boards
32-bit PCI: Four 32-bit / 33 Mhz PCI slot
USB (2.0) support: Two USB 2.0 port pin headers (sup-
ports up to 4 USB port)
Mechanical and Environmental
Dimensions: 106.5 x 327.66 mm
Power supply type: +12 V, +5 V, -12 V, -5 V, +3.3 V, +5
VSB
Power requirements: Refer to the CPU Board , add-on
card & peripherals
Operating temperature: 0 ~ 60° C
Weight: 0.3 kg
•
•
•
•
•
•
•
•
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw
This manual is for the PCE-5B05-04 Series Rev. A1
Part No. 200K5B0520
Printed in China
1st Edition
Dec. 2010
2 PCE-5B05-04 Startup Manual
Jumpers and Connectors
The backplane has a number of jumpers that allow you to
configure your system to suit your application.
The table below lists the function of each of the jumpers and
connectors.
Jumpers and Connectors
Jumpers
Label Function
PSON1
ATX/AT mode selection
ATX (Default): 2-3 pin closed
AT: 1-2 pin closed
Connectors
Label Function
SHBA1 ~ SHBD1
PICMG 1.3 CPU board slot
PPCI1 ~ PPCI4
32 Bit / 33MHz PCI Bus Slot
(Primary 3)
EATXPWR1
ATX2.0 24-pin power connector
ATX12V1
ATX 12V 4-pin power connector
VOLT1 Alarm board
FAN1 FAN connector
FAN2 FAN connector
FAN3 FAN connector
FANDEC1
Fan speed detector connector
SMBUS1
SMBus connector for chassis monitor
SMBUS2
SMBus connector for chassis monitor
JFP1 Power and reset button connector
IPMB1
IPMB connector
USB12 Two USB port pin header
USB34 Two USB port pin header
SATA1 SATA connector (reserved)
JTEMPA1 Sensor board connector (reserved)
JTEMPA2 Sensor board connector (reserved)
Connector Pin Definition
EATXPWER1
Pin Name
1
3.3 V
2 3.3 V
3 GND
4 5 V
5 GND
6 5 V
7 GND
8 Power OK
9 5 VSB
10 12 V
11 12 V
12 3.3 V
13 3.3 V
14 -12 V
15 GND
16 PSON#
17 GND
18 GND
19 GND
20 -5 V
21 5 V
22 5 V
23 5 V
24 GND
Jumpers and Connectors
PCE-5B05-04 Startup Manual 3
FANDEC1
Pin Name
1 FANIO1
2 FANIO2
3 FANIO3
4 N/A
5 N/A
6 N/A
7 N/A
SMBUS1 ~ SMBUS2
Pin Name
1 5 V
2 C-SMBCLK
3 C-SMBDAT
4 GND
IPMB1
Pin Name
1 IPMB_CLK
2 IPMB_DAT
3 GND
USB12
Pin Name
1 USBV0
2 USBV0
3 USBD0-
4 USBD1-
5 USBD0+
6 USBD1+
7 GND
8 GND
9 Null
10 GND
ATX12V1
Pin Name
1 GND
2 GND
3 12V
4 12V
EATX12V1
Pin Name
1 GND
2 GND
3 GND
4 GND
5 12 V
6 12 V
7 12 V
8 12 V
VOLT1
Pin Name
1 5 VSB
2 GND
3 GND
4 -5 V
5 5 V
6 3.3 V
7 -12 V
8 12 V
FAN1 ~ FAN4
Pin Name
1 GND
2 12 V
3 FANIO1 ~ FANIO4
Jumpers and Connectors
Jumpers and Connectors
