PCE-7129/5129/5029 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

1. 1 x PCE-7129/5129/5029 PICMG 1.3 Single Host Board

2. 1 x PCE-7129/5129/5029 Startup Manual

3. 1 x CD with utility

4. 1 x Serial ATA HDD data cables

5. 1 x Serial ATA HDD power cables

6. 1 x COM port cable kit

7. 1 x 2-port USB cable kit

8. 1 x Keyboard and mouse Y cable

9. 1 x Jumper package

10. 1 x Warranty card

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note 1: For detailed contents of PCE-7129/5129/5029,

please refer to the user manual in the enclosed

CD-ROM (in PDF format).

Note 2: Acrobat Reader is required to view any PDF

le. Acrobat Reader can be downloaded at: get.

adobe.com/reader (Acrobat is a trademark of

Adobe)

PCE-7129/5129/5029 LGA1151 Intel

®

Core

TM

i7/i5/i3/

Pentium

®

/Xeon

®

(PCE-7129) PICMG 1.3 Single Host

Board with (ECC) DDR4/M.2 (2280)/Dual GbE LAN

Startup Manual

General

• LGA1151 6th and 7th Intel

®

Core™ i7/i5/i3/Pentium

®

/

Xeon

®

•BIOS: AMI 128 Mb SPI BIOS

•Chipset:

- PCE-7129: Intel® C236

- PCE-5129: Intel® Q170

- PCE-5029: Intel® H110

•System memory:

- PCE-7129: Supports dual channel DDR4 1866/2133

16GB per DIMM with ECC; Max. capacity is up to 32GB

- PCE-5129/5029: Supports dual channel DDR4

1866/2133 16GB per DIMM without ECC; Max. capacity

is up to 32GB

Note1: Please select Intel® ECC supported processor to

enable ECC function.

Note2: Supports DDR4 1024M x 8 memory technology.

•SATA Ports:

- PCE-7129/5129 supports 5 SATA3.0 ports with SW Raid

0,1,5,10.

- PCE-5029 supports 4 SATA3.0 ports without Raid

function.

•M.2 Ports: PCE-7129/5129 supports M.2 2280 type M

module and compatible to both SATA3.0 and PCI Express

3.0 standard.

•Serial ports: Two RS-232 with pin headers

Note: PCE-5029VG SKU feature 1*pin header and 1* rear

COM port.

•Keyboard/mouse connector: Supports one standard

PS/2 keyboard and mouse connector and one external

6-pin header.

•Watchdog timer: 255 level timer intervals

•USB 2.0: PCE-7129/5129/5029: 7 * USB 2.0 (Pin-

header*2+USB Type-A*1+, 4 on backplane)

•USB 3.0:

- PCE-7129/5129: 5 * USB 2.0 (Pin-header*4+Rear USB

3.0 * 1)

- PCE-5029: 3 * USB 2.0 (Pin-header*2+Rear USB 3.0

* 1)

•GPIO: One programmable 8-bit GPIO pin-header

VGA Interface

•Chipset: Intel

®

HD Graphics

• Shared system memory is subject to OS

Ethernet Interface

•Chipset supports:

- LAN 1: I219LM(PCE-7129/5129); I219V(PCE-5029)

- LAN 2: I210AT(PCE-7129); I210AT (PCE-5129/5029)

•Connection: 2 on-board RJ-45 connectors with LED indica-

tors

Specications

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our

support website at:

http://www.advantech.tw/support

This manual is for the PCE-7129/5129/5029 Series

Rev. A3.

Part No. 2001512912

Printed in China

3rd Edition

October 2022
