PCE-4B12-03 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

•PCE-4B12-03 Startup Manual 1st Ed. p/n: 20024B1200

•2-year quality warranty card p/n: 2190000902

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Standard functions

•PICMG 1.3 slots: PCE-4B12-03 supports PICMG 1.3

half-size server grade SHB (PCE-4XXX series)

•PCIe slots: PCE-4B12-03 supports one PCIe p1-x8 slot, four

PCIe p1-x4 slot, three PCIe x1

•PCI slots: PCE-4B12-03 supports three PCI slots

Mechanical and Environment

•Dimensions: 315 x 185 mm

•Power supply voltage:+12 V, +5 V, -12 V, +3.3 V +5 VSB

•Power requirements: Refer to the CPU Board, add-on

card & peripherals

•Operating temperature: 0 ~ 60 °C

•Weight: 0.356 kg (weight of board)

PCE-4B12-03

Backplane: 12 Slot PICMG 1.3 Half-size BP for 14-

slot Rackmount Chassis, 1 x PCIe x8, 4 x PCIe x4,

3 x PCIex1, 3 x 32-bit/33MHz PCI

Startup Manual

Connectors

Label Function

SHBA1 ~ SHBB1 PICMG1.3 CPU board slot

PPCIE1, PPCIE3,

PPCIE5

PCIe p1-x1 slot

PPCIE2 PCIe p1-x8 slot

PPCIE4,

P1PCIE1-P1PCIE3

PCIe p1-x4 slot

EATXPWR1ATX2.0 24-pin power connector

PWR1Big 4 pin power connector

VOLT1Alarm board power connector

ATX12V1

ATX 12V Auxiliary 4-pin power

connector

FAN1~FAN7FAN connector

FANDEC1FAN detector connector

SMBUS1, SMBUS2

SMBus connector for chasis

monitor

JFP1

Power and Reset button con-

nector

Jumpers

Label Function

PSON1 ATX/AT Mode Selection

JFAN_CTRL1System Smart Fan Control

JGENSEL1 PCIe generation selection

connector

JCOMP1 Enable compatibility for

non-compliant Gen1 end point

Connectors Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://www.advantech.com.tw/support

This manual is for the PCE-4B12-03 series.

Part No. 20024B1200

Printed in China

1st Edition

November 2014
