Startup Manual 1
Packing List
Before installation, please make sure that you
have received the following:
• ADAM-3656 Product
• ADAM-3656 Startup Manual
If anything is missing or damaged, contact your
distributor or sales representative immediately.
Specications
System Functions
• Digital Input Channels: 8
• Digital Output: Open Collector
• Rated Voltage: 8~30 V
DC
• Rated Current: 200mA(max.load)/channel
• Pulse Output Frequency: 1KHz
• Over Voltage Protection: +40 V
DC
• Isolation Voltage: 2,000 V
DC
• Power Consumption: 1 w
• Operating Temp.: -40 ~ 70°C
• Warranty: 2 years
Notes
For more information on this and other Advantech
products, please visit our websites at:
http://www.advantech.com
For technical support and service:
http://www.advantech.com/support/
This startup manual is for ADAM-3656.
Part No: 2003A656001st Edition
October 2015
STARTUP MANUAL
ADAM-3656
8-ch Digital Output Module
Application Wiring
Overview
As an ADAM-3600 Extension I/O, ADAM-3656
provides 8-ch sink type isolated digital output.
The digital outputs are open-collector transistor
switches that you can control from the ADAM-
3600 main unit.
Caution:
When connecting jumpers or installing the card, you should disconnect the power to prevent surges
damaging sensitive electronic components.
